Bishamon ST30EWW Operation And Service Manual

Bishamon ST30EWW Operation And Service Manual

Battery powered hydraulic stackers

Advertisement

Quick Links

Read this manual carefully and understand completely before operating stackers. Keep filing this manual for
future reference. If this copy is lost, please contact your local supplier for a replacement.
Explanation of Terms and Symbols
Warning
In this manual, 「
very important for safe operations. As these are very Important to protect operators from accidents
resulting in personal injury and death, and damage to property, so make sure to read thoroughly and
understand fully before operation.
Warning
Caution
◎ Hazard or unsafe practice which, if not avoided, may result in DEATH or SEVERE PERSONAL INJURY and
PROPERTY DAMAGE.
DO NOT use lifter on slope, unlevel
or soft surface. Lifter may become position. SEVERE PERSONAL
unstable and /or uncontrollable.
SEVERE PERSONAL INJURY and
PROPERTY DAMAGE could result.
NEVER go under forks.
SEVERE PERSONAL INJURY or
DEATH could result.
DO NOT put hand near chain
sprocket or other moving parts.
SEVERE PERSONAL INJURY
could result.
Fully attach the battery terminal
cover. Danger of fire or electric
shock from short circuit could
result.
Caution
」 , 「
」 are defined and specified as below. Notice of Warnings are
Incorrect operation may result in serious injury or death of the operator.
Incorrect operation may result in injury and damage to the property.
Always travel with forks in lowered
INJURY and PROPERTY DAMAGE forks. SEVERE PERSONAL INJURY
could result.
DO NOT overload lifter.
ALWAYS stay within designated
capacity and load center rating.
KEEP FEET CLEAR of rolling
wheels that could result in
SEVERE PERSONAL INJURY.
SHOCK HAZARD !
Disconnect power plug before
opening Swtichboard and Control
Panel.
DO NOT load one fork more than
other and DO NOT load tips on
or DEATH could result.
Replace chain every four years or if
inspection reveals excessive wear on
links, pins, side plates and deformed,
bent, rusted or broken links.
USE ONLY in areas clear of all
personnel and objects to prevent
severe personal injury and property Handle battery after fully reading
damage.
Battery is not charged upon delivery. Pease
charge after reading this Operation and Service
Manual and the manual supplied with charging
- 1 -
NEVER sit, stand or ride on forks.
SEVERE PERSONAL INJURY or
DEATH could result.
DO NOT use in areas of multi level
floor surface that could create loss
of control and result in SEVERE
PERSONAL INJURY.
KEEP AWAY from open flame
when charging battery.
the instruction manual.
