- Page 1 Optima SO218/318 OWNER'S MANUAL Manual No. 513571 Aug. 2001, Rev. 2...
- Page 3 Need Parts or Service? We stock the parts you need. Our Technicians are factory trained and are certified in the Stoelting Technicare program. CALL Distributor: _________________________ Phone No.: _________________________ Model No.: _______________________ Serial No.: _______________________ Purchase Date: ____________________ Start-Up Date:____________________...
- Page 5 If problems develop or questions arise in connection with installation, operation or servicing of the freezer, contact the company at the following location: STOELTING, LLC 502 Hwy 67 Kiel, WI 53042-1600 OWNER'S MANUAL FOR MODEL SO218/318 STOELTING FLOOR MODEL FREEZER 920-894-2293 Fax: 920-894-7029...
-
Page 7: Table Of Contents
Sanitizing ... Cleaning & Sanitizing of SO318 with Fill-o-matic II and Fill-o-matic III ... Initial Freeze Down and Operation ... 3.10 Removing Product ... 3.11 SO218/318 Operation ... 4. PREVENTATIVE MAINTENANCE Routine Cleaning ... Preventative Maintenance ... Extended Storage ... - Page 8 FIGURE TITLE Model SO218/318 ... 1 Dispenser Specifications ... 2 Leveling Unit ... 3 Controls ... 5 Disassembling Freezer ... 6 Front Door and Auger Assembly ... 6 Rear Seal Assembly ... 6 Retainer Clip ... 7 Consistency Control Knob ... 8 Fill-o-matic II ...
-
Page 9: Introduction
1.1 REMOTE POSSIBILITIES The Stoelting Optima delivers frozen drink profits by the pitcher. The Model SO218/318 is a high-volume producer of ready-to-serve frozen cocktails or frozen neutral base for those special drink recipes. From an extra-small space, the Optima’s compact design and high capacity output will give you extra-large profits. -
Page 10: Dispenser Specifications
1.3 DISPENSER SPECIFICATIONS Electrical Refrigeration 208/230/60/1 HFC-404A environmentally- 20amp circuit & plug friendly refrigerant 12 running amps 2 HP (14,800 BTUH) high- 1/2 HP Drive Motor efficiency compressor Air or water cooled. Figure 2. Dispenser Specifications Crated Dimensions Width: 22" (55.9cm) Depth: 30"... -
Page 11: Installation Instructions
If concealed damage and/or shortage is found later, advise the carrier within 10 days and request inspection. The customer must place claim for damages and/or shortages in shipment with the carrier. Stoelting, Inc. cannot make any claims against the carrier. SECTION 2... -
Page 12: Installing Permanent Wiring
E. Connect the power cord. The plug is designed for 208/ 230 volt/20 amp duty. The unit must be connected to a properly grounded receptacle. The electrical cord furnished as part of the freezer has a three prong grounding type plug. The use of an extension cord is not recommended. -
Page 13: Initial Setup And Operation
3.1 OPERATOR'S SAFETY PRECAUTIONS SAFE OPERATION IS NO ACCIDENT; Observe these rules: A. Know the freezer. Read and understand the Operating Instructions. B. Notice all warning labels on the freezer. C. Wear proper clothing. Avoid loose fitting garments, and remove watches, rings or jewelry which could cause a serious accident. -
Page 14: Cleaning The Freezer Parts
Figure 5. Disassembling Freezer E. Remove the spigot body from the front door bypulling the retaining pin out of the spigot handle. Push the spigot body thru the bottom of the front door. F. Remove the agitator assembly from the freezer. Pull the agitator assembly out of the freezer barrel. -
Page 15: Sanitizing
FREEZER MAY CAUSE CORROSION OF STAIN- LESS STEEL PARTS. In general, sanitizing may be conducted as follows: A. SO218: Prepare 4 gallons (15 liters) of sanitizing solution following manufacturers instructions, then pour into hopper, brush hopper walls, and inside of hopper cover. -
Page 16: Cleaning & Sanitizing Of So318 With Fill-O-Matic Ii And Fill-O-Matic Iii
3.8 CLEANING & SANITIZING OF S0318 WITH FILL-O-MATIC II AND FILL-O-MATIC III A. Empty freezer & mix container of product. B. Mix 4 gallons of warm detergent water and pour into mix container, brush mix container, pick up hose and draw tube. -
Page 17: So218/318 Operation
SO218/318 OPERATION INFORMATION FOR SERVICE PERSONNEL The SO218/318 is a cocktail/slush freezer. It is available in 208-230 volt, either air-cooled or water-cooled. The air-cooled version has front-to-back airflow requiring three inches of air space in the front and back for proper refrigeration. -
Page 19: Routine Cleaning
4.1 ROUTINE CLEANING To remove spilled or dried mix from the freezer exterior, simply wash in the direction of the finish with warm soapy water and wipe dry. Do not use highly abrasive materials as they will mar the finish. 4.2PREVENTATIVE MAINTENANCE It is recommended that a maintenance schedule be followed to keep the freezer clean and operating prop-... -
Page 21: Replacement Parts Information
REPLACEMENT PARTS INFORMATION 5.1 ORDERING PARTS To assure receipt of the proper replacement parts, supply your dealer or distributor with the following information: A. MODEL NUMBER of equipment. B. SERIAL NUMBER of model (stamped on nameplate). C. PART NUMBER, PART NAME, AND QUANTITY NEEDED. -
Page 23: Accessories
The Fill-O-Matic II is a self contained auto-fill system designed to be used with the Model SO318 and DQSO318 Freezer. The pump is built onto the cover of a 10 gallon mix vat. A draw tube extends to the bottom of the container to supply the pump with mix, the mix then passes thru a screen, thru the pump and discharges thru a hose to the freezer. -
Page 24: Fill-O-Matic Ii
On/Off Switch Strainer 115 Volt 15 Amp Plug Figure 10. Fill-o-matic II... -
Page 25: Fill-O-Matic Iii
The Fill-O-Matic III is a gas powered auto-fill system designed to be used with Slush and Cocktail Freezers. The pump is built to hang on the side of a 10 gallon mix vat. The pump can be driven by either regulated CO , nitrogen or filtered compressed air. -
Page 26: Fill-O-Matic Iii
Figure 11. Fill-o-matic III Mix Outlet Outlet Gas Inlet Inlet... -
Page 27: Fill-O-Matic Connections
Gas Powered To Freezer Electric From Auto Fill Note: Tubing Sold Separately... - Page 29 The warranty period for deinstallation/reinstallation of the affected component from/into the equipment is extended to twelve (12) months on the following models: SO218, SO318, SO328. The warranty period for the drive motor to be free of defects in materials and workmanship extended to five (5) years on the following models: SO218, SO318, SO328.
