- Page 1 S E M B L A N C E M O D U L A R S Y S T E M COMPONENT ASSEMBLY INSTRUCTIONS NO POWER TOOLS CORNER DESK 15049 B D I U S A . C O M TWO PERSON ASSEMBLY...
- Page 2 Position the Template (CC) in the desire location where the corner desk will be positioned. While the second person holds the desk frame on its side position, attach Corner Leg (CD) to the underside of the Desk Frame Assembly (CB) using Screws (E). E x 4 G x 1...
- Page 3 Partially install Screws (E) on the second hole from the top of the panel. PANEL While the second person holds a panel up to the edge of the Template, lower the Desk Frame Assembly into position fitting the bodies of the the screws into the slots of the Desk Frame.
- Page 4 While the second person holds the Desk Frame, bring the second panel up to the edge of the Template and align the slots of the Desk Frame with the Screw (E) bodies. Tighten the Screws (E) underneath that fit into the slots of the Desk Frame. At this time, the cardboard template may be removed.
- Page 5 With the help of another person, carefully lower the Glass Top (CA) onto the frame. Register the steel discs on underside of glass into the holes on the frame; then attach the glass using Machine Screws (O) and Hex Drive (G). NOTE: Do not over-tighten screws! 8: Magnets Located inside the Corner Leg (CD) are...
- Page 6 Magnetically attach the Corner Leg Cover (CE) to the Corner Leg (CD). Leveler If needed, adjust leveler on Corner Leg using Allen Wrench (I). Level each Panel as it is being assembled. Use Leveler Wrench (F) to adjust the height of the Panel, if necessary.
