  • Page 1 SOLAR2R Standalone proximity keypad...

  • Page 2: Recommended Power Supplies

    SOLAR2R keypad Surface-mount. Ce document est la propritété exclusive de CDVI, il ne peut être communiqué à des tiers sans son autorisation. Plan M1849 This document is the exclusive property of CDVI and it may not be disclosed to others without permission.
  • Page 3 Recommendations»). Place the back visible (about 2mm) on the top-back connect the cable (refer to wiring plate of the SOLAR2R on the wall and of the reader. diagram on page 4). the bracket of the remote electronic...

  • Page 4: Wiring Diagram

    SOLAR2R Standalone proximity keypad 5] WIRING DIAGRAM 12 VDC ADC335 Black SPR12, SR12, … Green V5SR, PROG Reset SIR12, PROG Memory … Door alarm stay open Door 2 same as Door 1 above Door2 Door1 Yellow Dark Blue Grey Don’t forget to connect the door contacts...

  • Page 5: Reader Configuration

    SOLAR2R Standalone proximity keypad 6] READER CONFIGURATION AND RESETTING THE CONTROLLER 1. Reader configuration : - On the readers make sure both dipswitches are positioned to off. 1 reader configuration : - Press 1B, the reader turns blue and position both dipswitches on the reader to ON.

  • Page 6: Programming Chart

    10s and periodical reset of the reader. Orange LED ON Ce document est la propritété exclusive de CDVI, il ne peut être communiqué à des tiers sans son autorisation. Plan M1849 This document is the exclusive property of CDVI and it may not be disclosed to others without permission.
  • Page 7 SOLAR2R Standalone proximity keypad Default values - Inter terms duration : 10 seconds 3 successive entries (cards - User code lenght : 5 digits or codes) = Keypad locks for - Mode : cards or keypad 30 secondes. - Master code : 1 2 3 4 5...
  • Page 8 Styrenhet till kodlås SOLAR2R Utanpåliggande montage. Ce document est la propritété exclusive de CDVI, il ne peut être communiqué à des tiers sans son autorisation. Plan M1849 This document is the exclusive property of CDVI and it may not be disclosed to others without permission.
  • Page 9 SOLAR2R Standalone EM-läsare med knappsats 4] MONTERING Kontrollera avståndet mellan Placera skumtätningen mellan mon- För igenom kabeln genom hålet i SOLAR2R knappsatsen tageplattan och väggen. montageplattan, sätt i pluggarna styrenheten (Se sid 8 «Information Skumtätningen skall vara synlig och skruva fast montageplattan.
  • Page 10 SOLAR2R Standalone EM-läsare med knappsats 5] Kopplingsschema 12 VDC 12Vdc ADC335 ADC335 Röd Black Svart SPR12, Elslut- SR12, bleck … Green Grön Röd V5SR, Magnet- Återställning PROG Reset SIR12, PROG lås Memory … Larm om dörr förblir öppen Door 2 same as Door 1 above Dörr 2 kopplas på...

  • Page 11: Kompletterande Information

    SOLAR2R Standalone EM-läsare med knappsats 6] KONFIGURERA KNAPPSATSER OCH FABRIKSÅTERSTÄLLNING 1. Konfigurera knappsatser : - Försäkra dig om att dipswitcharna på knappsatserna står i läge OFF 1 knappsats : - Tryck 1B, läsaren lyser blått och ställ båda dipswitcharna i läge ON.
  • Page 12 - Kommunikationsproblem: Aktiverar larmreläet Orange LED lyser Ce document est la propritété exclusive de CDVI, il ne peut être communiqué à des tiers sans son autorisation. Plan M1849 This document is the exclusive property of CDVI and it may not be disclosed to others without permission.
  • Page 13 SOLAR2R Standalone EM-läsare med knappsats Standardvärden - Standby : 10 sekunder 3 misslyckade försök (kort - Kodlängd : 5 siffror eller kod) = Knappsatsen - Läge : kort eller kod låses i 30 sekunder. - Masterkod : 1 2 3 4 5 - Upplåsningstid : 5 sekunder...
