ADTRAN NetVanta 900 Series Hardware Installation Manual

Hide thumbs Also See for NetVanta 900 Series:

Quick start manual (2 pages)

Configuration manual (43 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

1200785L1

1200786L1

1200788L1

1200791L1

1200792L1

1200793L1

1200798L1

61200788L1-34B

July 2004

NetVanta 950 IAD

Hardware Installation Guide

NetVanta 900 Series AC Power Supply

NetVanta 900 Series AC Chassis

NetVanta 950 IAD System Controller

NetVanta 900 Series Octal FXS Module

NetVanta 900 Series Octal FXO Module

NetVanta 900 Series Octal Ethernet Switch Module

NetVanta 950 IAD T1/V.35 Expansion Module

Table of Contents

Need help?

Do you have a question about the NetVanta 900 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ADTRAN NetVanta 900 Series

Page 1 NetVanta 900 Series AC Chassis 1200788L1 NetVanta 950 IAD System Controller 1200791L1 NetVanta 900 Series Octal FXS Module 1200792L1 NetVanta 900 Series Octal FXO Module 1200793L1 NetVanta 900 Series Octal Ethernet Switch Module 1200798L1 NetVanta 950 IAD T1/V.35 Expansion Module 61200788L1-34B July 2004...
Page 2 To the Holder of this Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Page 3 4. Use only the power cord, power supply, and/or batteries indicated in the manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for special disposal instructions. Save These Important Safety Instructions 61200788L1-34B © 2004 ADTRAN, Inc.
Page 4 The end user/customer will be responsible for filing an affidavit with the local exchange carrier when connecting unprotected customer premise equipment (CPE) to 1.544 Mbps or subrate digital services. • Until such time as subrate DTE is registered for voice applications, the affidavit requirement for subrate services is waived. © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 5 I agree to provide ______________________ (telco’s name) with proper documentation to demonstrate compliance with the information as provided in the preceding paragraph, if so requested. _________________________________Signature _________________________________Title _________________________________ Date Transcribed and sworn to before me This ________ day of _______________, _______ _________________________________ Notary Public My commission expires: _________________________________ 61200788L1-34B © 2004 ADTRAN, Inc.
Page 6 Advance notification and the opportunity to maintain uninterrupted service are given. 4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected or it is certain the equipment is not malfunctioning.
Page 7 The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices should not exceed five (5). 61200788L1-34B © 2004 ADTRAN, Inc.
Page 8 Hardware Installation Guide NetVanta 950 IAD Product Warranty ADTRAN will repair and return this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found at www.adtran.com/warranty. Product Registration Registering your product helps ensure complete customer satisfaction.
Page 9 Your reseller should serve as the first point of contact for support. If additional support is needed, the ADTRAN Support web site provides a variety of support services such as a searchable knowledge base, updated firmware releases, latest product documentation, service request ticket generation and trouble-shooting tools.
Page 11: Table Of Contents
NetVanta 900 Series Octal FXS Module (P/N 1200791L1) ........22 NetVanta 900 Series Octal FXO Module (P/N 1200792L1) ........23 NetVanta 900 Series Octal Ethernet Switch Module (P/N 1200793L1) ....24 4. Unit Installation ........................25 Tools Required ........................ 25 Mounting Options ......................
Page 12 Figure 7. NetVanta 900 Series Octal FXS Module ....... 22 Figure 8.
Page 13: Introduction To The Netvanta 950 Iad Solution
ADTRAN Operating System (AOS). The NetVanta 950 IAD Family includes the NetVanta 900 Series AC Chassis, AC power supply, system controller, and various modules for voice and data applications. Currently, the NetVanta 950 IAD Family offers the Octal FXS and Octal FXO Modules for voice applications, a T1/V.35 Expansion Module for data...
Page 14: Unpack And Inspect The System
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (see Product Warranty, on page 8).
Page 15: Product Overview
NetVanta 950 IAD Hardware Installation Guide Product Overview PRODUCT OVERVIEW Reviewing the Chassis Front Panel Design Figure 1 shows the NetVanta 950 front panel. NetVanta 900 Series ANLG FXO TRUNKS 1200792L1 1200792L1 1200792L1 Figure 1. NetVanta 950 Front Panel Layout 61200788L1-34B ©...
Page 16: Front Panel Leds
Figure 2 and Figure 3 on page 17 show the NetVanta 950 side panels. All voice connections are provided through two 50-pin amphenol connectors (located on the right side panel). The left side panel contains the battery backup connector, the T1 network connections, the alarm contacts, the power connection, and the ground lug. © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 17: Figure 2. Netvanta 950 Right Side Panel Layout
NetVanta 950 IAD Hardware Installation Guide Product Overview Voice Ports (Amphenol) Figure 2. NetVanta 950 Right Side Panel Layout Network Connections Alarm Contacts Power Battery Connection Backup Connection Ground Figure 3. NetVanta 950 Left Side Panel Layout 61200788L1-34B © 2004 ADTRAN, Inc.
Page 18: Side Panel Interfaces
Battery Backup Connection The NetVanta 950 IAD provides a modular plug for connecting to an alternate -48 VDC power supply (ADTRAN power supply/battery charging unit P/N 1175044L1). Refer to the Battery Backup Unit on page 29 for more details on this connection.
Page 19: Modules
Figure 4. Voice Connector Pin Assignment MODULES The NetVanta 900 Series offers several modules designed to meet a variety of networking requirements. The modules are of three types: controller, expansion modules, and access modules. The following modules are available for the NetVanta 950: •...
Page 20: Netvanta 950 Iad Controller (P/N 1200788L1)
UL 60950, Third Edition/CSA C22.2, No. 60950 • Industry Canada CS-03 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: 95% noncondensing Figure 5. NetVanta 950 Controller Module © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 21: Netvanta 950 T1/V.35 Expansion Module (P/N 1200798L1)
UL 60950, Third Edition/CSA C.22.2, No. 60950 • Industry Canada CS-03 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: 95% non-condensing Figure 6. NetVanta 950 T1/V.35 Expansion Module 61200788L1-34B © 2004 ADTRAN, Inc.
Page 22: Netvanta 900 Series Octal Fxs Module (P/N 1200791L1)
NetVanta 900 Series Octal FXS Module (P/N 1200791L1) The NetVanta 900 Series Octal FXS Module (shown in Figure 7) provides eight voice interfaces for the NetVanta 950 system. Refer to Table A-8 on page 38 and Table A-9 on page 40 for the voice connector pinout.
Page 23: Netvanta 900 Series Octal Fxo Module (P/N 1200792L1)
NetVanta 900 Series Octal FXO Module (P/N 1200792L1) The NetVanta 900 Series Octal FXO Module (shown in Figure 8) provides eight analog trunk interfaces for the NetVanta 950 IAD System. Refer to Table A-8 on page 38 and Table A-9 on page 40 for the voice connector pinout.
Page 24: Netvanta 900 Series Octal Ethernet Switch Module (P/N 1200793L1)
Modules NetVanta 950 IAD Hardware Installation Guide NetVanta 900 Series Octal Ethernet Switch Module (P/N 1200793L1) The Ocatl Ethernet Switch Module (shown in Figure 9) provides eight 10BaseT/100BaseTX (RJ-48C) interfaces for connection to local area networks (LANs). Each interface supports auto-negotiation and provides auto MDI/MDIX crossover.
Page 25: Unit Installation
• Battery Backup Unit on page 29 For information on configuring a specific application, refer to the quick configuration documents provided on your Adtran OS Documentation CD. For details on the command line interface, refer to the Command Reference Guide (also included on your CD).
Page 26: Mounting Options
Proceed to the steps given in the Installing Modules and Grounding Instructions on page 28 and Supplying Power to the Unit on page 29. Figure 10. Wallmounting the NetVanta 950 © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 27: Rack Mounting The Netvanta 950
Proceed to the steps given in Installing Modules and Grounding Instructions on page 28 and Supplying Power to the Unit section on page 29. NetVanta 900 Series Figure 11. Rack Mounting the NetVanta 950 IAD The NetVanta 950 IAD system is intended to be installed, maintained, and serviced by qualified personnel only.
Page 28: Installing Modules
The ring terminal should be installed using the appropriate crimping tool (AMP P/N 59250 T-EAD Crimping Tool or equivalent). © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 29: Grounding For Ac Power
• Maximum recommended ambient operating temperature is 50 BATTERY BACKUP UNIT The ADTRAN Battery Backup Unit is an optional device designed as a backup DC power supply for the NetVanta 950. The Battery Pack connects to the NetVanta 950 through a 6-foot charge/discharge, 2-conductor wire with a keyed modular plug (included with the Battery Backup Unit).
Page 30: Unpack And Inspect
• This device may not cause harmful interference, and • This device must accept any interference that may cause undesired operation. Changes or modifications not expressly approved by ADTRAN could void the user’s authority to operate this equipment. © 2004 ADTRAN, Inc.
Page 31: Installation Of The Battery Pack
There are three installation arrangements: • Single Battery Pack, wallmount (standard) • Single Battery Pack, rackmounted • Double Battery Packs arranged back-to-back and rackmounted The Battery Pack does not need to be opened for mounting. 61200788L1-34B © 2004 ADTRAN, Inc.
Page 32: Figure 13. Battery Pack Mounting Dimensions
Insert the two lower screws through the tabs and tighten securely. Use cable tie-downs as appropriate. The NetVanta 950 IAD battery connection from the Battery Pack should be directly connected to the BATTERY port on the left side of the chassis. © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 33: Maintenance
• To order replacement batteries, reference the following part number: 1975044L1 (12 V replacement Battery). ADTRAN is an environmentally-friendly company. Therefore, we encourage the proper recycling and handling of the batteries. Federal and State laws prohibit the improper disposal of all lead acid batteries.
Page 35: Appendix A. Pinouts
Transmit data toward the network–TIP — UNUSED Table A-2. Alarm Contacts Description Normally Closed Normally Opened Common Controller Pinouts Table A-3. 10/100BaseT Ethernet Port Pinout Name Description Transmit Positive Transmit Negative Receive Positive — UNUSED Receive Negative — UNUSED 61200788L1-34B © 2004 ADTRAN, Inc.
Page 36: Table A-4. Console Port (Dce) Pinout
Expansion Module Interfaces Table A-5. T1 1/1 Connector Pinout Name Description Receive data from the network–RING 1 Receive data from the network–TIP 1 — UNUSED Transmit data toward the network–RING Transmit data toward the network–TIP — UNUSED © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 37: Table A-6. V.35 Connector Pinout
External TX Clock (ETC-B) from DTE Test Mode (TM) to DTE Ethernet Switch Module Pinout Table A-7. 10/100BaseT Ethernet 0/1 Port Pinout Name Description Transmit Positive Transmit Negative Receive Positive — UNUSED Receive Negative — UNUSED 61200788L1-34B © 2004 ADTRAN, Inc.
Page 38: Table A-8. Voice Interface Pinout (Slots 2 - 4)
Slots 2-4 Slot 2/4 - Tip Slots 2-4 Slot 2/5 - Tip Slots 2-4 Slot 2/6 - Tip Slots 2-4 Slot 2/7 - Tip Slots 2-4 Slot 2/8 - Tip Slots 2-4 Slot 3/1 - Tip © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 39 Slots 2-4 Slot 4/4 - Tip Slots 2-4 Slot 4/5 - Tip Slots 2-4 Slot 4/6 - Tip Slots 2-4 Slot 4/7 - Tip Slots 2-4 Slot 4/8 - Tip Slots 2-4 Reserved - Future 61200788L1-34B © 2004 ADTRAN, Inc.
Page 40: Table A-9. Voice Interface Pinout (Slots 5 - 7)
Slots 5-7 Slot 5/4 - Tip Slots 5-7 Slot 5/5 - Tip Slots 5-7 Slot 5/6 - Tip Slots 5-7 Slot 5/7 - Tip Slots 5-7 Slot 5/8 - Tip Slots 5-7 Slot 6/1 - Tip © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 41 Slots 5-7 Slot 7/4 - Tip Slots 5-7 Slot 7/5 - Tip Slots 5-7 Slot 7/6 - Tip Slots 5-7 Slot 7/7 - Tip Slots 5-7 Slot 7/8 - Tip Slots 5-7 Reserved - Future 61200788L1-34B © 2004 ADTRAN, Inc.
Page 43: Appendix B. Adtran Aos Supported Mibs
APPENDIX B. ADTRAN AOS SUPPORTED MIBS ADTRAN AOS platforms support the MIBs listed in Table B-1. For the most up-to-date MIB list, please visit our website at www.adtran.com. Table B-1. MIBs Supported in the AOS Name Description Notes DS1-MIB 2495 Describes DS1, E1, DS2, and E2 interface objects.
Page 44: Table B-2. Notes Regarding Mib Exclusions
Note 4: IF exclusions IfTable • ifInNUcastPkts • ifOutNUcastPkts • ifOutQLen • ifSpecific ifXTable • ifHCInUcastPkts • ifHCInMulticastPkts • ifHCInBroadcastPkts • ifHCOutUcastPkts • ifHCOutMulticastPkts • ifHCOutBroadcastPkts ifStackTable ifTestTable IfRcvAddressTable Note 5: MAU exclusions rpMauTable rpJackTable broadMauBasicTable © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 45 Note 7: IP exclusions ipForwarding ipDefaultTTL ipInReceives ipInHdrErrors ipInAddrErrors ipForwDatagrams ipInUnknownProtos ipInDiscards ipInDelivers ipOutRequests ipOutDiscards 61200788L1-34B © 2004 ADTRAN, Inc.
Page 46: Table B-3 Traps Supported In The Aos
Note 8: IP-FORWARD exclusions ipForwardNumber ipForwardTable ipCidrRouteNumber Table B-3. Traps Supported in the AOS Name Cold Start 1.3.6.1.6.3.1.1.5.1 Warm Start 1.3.6.1.6.3.1.1.5.2 Link Down 1.3.6.1.6.3.1.1.5.3 Link Up 1.3.6.1.6.3.1.1.5.4 Authentication Failure 1.3.6.1.6.3.1.1.5.5 © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 47 26 DC power 29 DSX-1 interface 36 NC 18 NetVanta 950 IAD controller 20 NetVanta 950 IAD front panel 15 ethernet normally closed 18 interface 20 normally open 18 Ethernet switch module 24 61200788L1-34B © 2004 ADTRAN, Inc.
Page 48 14 installation of the NetVanta 950 26 side panel WAN 18 interfaces 18 interface 18 side panels 16 LED 16 slot 1 21 WAN/T1 interface pinout 35 specifications 13 battery pack 33 supplying power 29 © 2004 ADTRAN, Inc. 61200788L1-34B...
Page 49 NetVanta 900 Series Octal FXS Module (P/N 1200791L1) ........22 NetVanta 900 Series Octal FXO Module (P/N 1200792L1) ........23 NetVanta 900 Series Octal Ethernet Switch Module (P/N 1200793L1) ....24 4. Unit Installation ........................25 Tools Required ........................ 25 Mounting Options ......................
Page 51 Figure 7. NetVanta 900 Series Octal FXS Module ....... 22 Figure 8.
