NetVanta Unified Communications Demo Kit
Quick Start Guide
N
V
U
C
ET
ANTA
NIFIED
The NetVanta Unified Communications (UC) Demo Kit
consists of a custom Pelican 1610 case with built-in dolly
and foam inserts designed to cradle and cushion the
NetVanta UC components.
Included in the kit are the following:
• One NetVanta 7100 Chassis (1200796E1)
• One ADTRAN IP 5000 Conference Phone (1200753G1)
• One ADTRAN VVX Expansion Module (1200952G1)
• One ADTRAN VVX 600 (1200856G1)
• One ADTRAN VVX 500 (1202855G1)
• One ADTRAN VVX 400 (1200854G1)
• One ADTRAN VVX 300 (1200853G1)
• Two VVX High Definition USB Cameras (1200954G1)
64200796L1-13E
D
OMMUNICATIONS
EMO
Copyright © 2014 ADTRAN, Inc.
P
1610 C
ELICAN
The features of the Pelican 1610 case include:
• Unbreakable, watertight, airtight, dustproof, chemical
resistant, and corrosion proof
• Ultra-high impact structural copolymer for strength, light
weight, and durability
• Easy-open double throw ABS latches that seal perfectly
• Replaceable 0.25-inch (6.4-mm) neoprene O-ring seal
• Automatic pressure equalization valve for changes in
altitude or temperature
• Strong polyurethane 2-inch (5-cm) wheels with stainless
steel bearings
• Four layer, custom-contoured foam
• Fold-down front and side handles
• Retractable extension handle with effortless-release
latch
• Padlock protectors for added strength and extra security
• Unconditional Lifetime Warranty from Pelican
K
• External dimensions: 24.71-inch H x 19.58-inch D x
IT
11.93-inch W (63-cm H x 50-cm D x 30-cm W)
• Weight: Approximately 48 lb (21.77 kg)
• Color: Black case with white ADTRAN logo
F
I
OAM
NSERTS
The custom-cut foam inserts are layered four deep in the
case. The Top Tray contains compartments for a laptop,
documentation, and miscellaneous cables. The second
layer (Tray 2) contains the NetVanta 7100 Chassis. The
third layer (Tray 3) holds the VVX 300 and VVX 400 IP
phones, handsets, and conference phone. The bottom layer
(Tray 4) holds VVX 500 and VVX 600 IP phones, phone
stands, handsets, VVX expansion module, and USB
cameras.
P/N 4202797G1
F
ASE
EATURES
March 2014
Page 1
