EcoFlow RIVER Max
Contact us:
www.ecoflow.com
User Manual
1. Keep EcoFlow™ RIVER Max ("RIVER Max") and the accessories
dry. DO NOT expose the product and accessories to high heat.
2.Never disassemble, puncture, shock, damage, or incinerate
the product.
3. Recycle and dispose of RIVER Max in accordance with local
laws and regulations.
4. Pay attention to safety when handling the RIVER Max.
WARNING
5. Children or people with disabilities should use the product
under adult supervision.
Advertisement
Table of Contents
Related Manuals for EcoFlow RIVER Max
Summary of Contents for EcoFlow RIVER Max
- Page 1 DO NOT expose the product and accessories to high heat. 2.Never disassemble, puncture, shock, damage, or incinerate the product. 3. Recycle and dispose of RIVER Max in accordance with local laws and regulations. 4. Pay attention to safety when handling the RIVER Max.
- Page 2 3. Never install or remove other modules from the RIVER Max when it is turned on. DO NOT plug or unplug oth- er modules when the power of the product is turned on, otherwise the power interface may be damaged.
- Page 3 9. DO NOT put the product in a microwave oven or in a pressurized container. 10. DO NOT allow pins, wires, or other metal pieces to enter the RIVER Max case, outlets, or controls. Metal piec- es may short circuit the product.
- Page 4 68°F to 77°F (20°C to 25°C). 2. If the product is not used for a long time, the battery life may be reduced. 3. Discharge RIVER Max to 30%, then charge to 85% every 3 months to keep the battery healthy.
- Page 5 NOTICE To turn RIVER Max on or off, you need to PRESS and HOLD the ON/OFF System Power Button. To turn on the AC power outlet, you need to PRESS and HOLD the AC Button after turning on RIVER Max. Users can turn off AC power when they don’t need it and save power.
-
Page 6: Table Of Contents
CONTENTS EcoFlow App Download Guide RIVER Max Features Ambient Light LCD Display Introduction Protection and Error Information Connecting the Solar Panels Entry-Level UPS AC X-Boost Mode Technical Specifications How to Recharge RIVER Max RIVER Max FAQ What’s in the Box... -
Page 7: Ecoflow App Download Guide
EcoFlow App Download Guide 1. Download the EcoFlow App Search for “EcoFlow” in Google Play Store or App Store to download the app. You can also scan this QR code with your phone, or you can enter the down- load link in your browser: https://ecoflow.com/pages/ecoflow-app... -
Page 8: River Max Features
12. X-Stream Charging Input Port 13. Overload Protection Switch 14. Solar Charge/Car Charge Input Port 15. Power Earth Screw 16. Ambient Light 220-240V region*Dedicated AC Output *EcoFlow has designed different AC output sockets following the local regulations of different countries. -
Page 9: Ambient Light
Charging: The blue light will move from left to right of the panel, repeatedly. 2. Customizing the Ambient Light Enter Module Settings on the EcoFlow app to access ambient light features. • The ambient light can be turned on / off, kept on, or put on a standby mode. -
Page 10: Lcd Display Introduction
Please cool down the product before use. e. Low Temperature Indicator When the temperature of the RIVER Max is too low, a low-temperature warning icon appears on the screen. Please warm up the product properly before use. f. Fan Indicator Shows the fan speed, which is controlled by RIVER Max automatically. -
Page 11: Protection And Error Information
Overload Warning The overload icon appears along with a second icon indicating what part of the RIVER Max is in an overload condition. Battery Indicator Refers to the battery Port Usage Indicators Extra Battery Indicator The Extra Battery icon will appear when Extra Battery is connected to the main model. - Page 12 (For more information about X-Boost function, go to P10. AC and High-Temperature icons flash together. Inverter High-Temperature Turn off RIVER Max and let it cool down. Then turn Protection System Power On and AC Power On.
- Page 13 Restart RIVER Max, make sure all electrical appliances Car Charger Overload are used within the specified power range. Car and High-Temperature icons flash together. Turn RIVER Max off and let it cool down. Turn System Car Charger High-Tempera- ture Protection Power On then DC Power On.
-
Page 14: Connecting The Solar Panels
1. Connect the solar panel to the MC4 to XT60 Solar Charging Cable. Connect the XT60 connector to the RIVER Max’s XT60 input port to charge the RIVER Max. Users can connect up to 2 sets of solar panels in parallel to the MC4 port as shown in Example 2. -
Page 15: Entry-Level Ups
RIVER Max is connected to an AC power source (your devices or appliances connected the RIVER Max AC sock et will get power from the AC power source, not the RIVER Max battery). When the AC power source loses power suddenly, the RIVER Max will switch to provide power to the devices and appliances connected to it in <30ms. -
Page 16: Ac X-Boost Mode
Entry-Level UPS User Guide Users can connect the AC charging cable of RIVER Max to an AC power source, connect a device to RIVER Max, and turn on the AC switch to automatically enter the entry-level UPS mode. When the AC power source is cut off, power will be supplied from the battery of RIVER Max to power your device (as shown below).*... -
Page 17: Technical Specifications
Technical Specifications General Specs Net Weight 17 lbs (7.7kg) Dimensions 11.4 x 7.3 x 9.3 in (28.9 x 18.4 x 23.5 cm) Capacity 576Wh (28.8V) Testing and certification UL Standard, CE, FCC, RoHS, RCM Outputs 600W (Surge 1200W) total, 120Vac (50Hz/60Hz) / AC Output (x3) / 230Vac (50Hz/60Hz) (x2 International Version) Full Sine Wave... -
Page 18: How To Recharge River Max
How to Recharge RIVER Max RIVER Max has an AC charging port and an XT60 charging port located on the side. RIVER Max can be charged with a 12V car charger, solar panels, or with AC power. Example 1: X-Stream Charging... -
Page 19: What's In The Box
ER Max near water. Please turn off the RIVER Max and store it within its recommended use and storage tem- perature range. If you need to store the RIVER Max for a long time, please discharge the RIVER Max to 30%, then charge it to 85% every 3 months.
