EcoFlow RIVER Pro User Manual

Hide thumbs Also See for RIVER Pro:

Advertisement

Quick Links

x
Download this manual
7
Features of the River Pro
9
Lcd Display Introduction
13
Solar Panel Connection
14
Entry-Level Ups
17
Technical Specifications
Table of Contents
EcoFlow RIVER Pro
Contact us:
www.ecoflow.com
User Guide
1. Keep EcoFlow RIVER Pro (hereinafter referred to as RIVER Pro)
and the accessories dry and do not expose them to high heat.
2. Never disassemble, puncture, shock, crash, or incinerate the product.
3. Recycle and dispose of RIVER Pro in accordance with the
local regulations.
4. Pay attention to safety when handling the RIVER Pro.
WARNING
5. Children or people with disabilities should use the machine
under the protection of the supervisor.

Advertisement

Table of Contents
loading

Related Manuals for EcoFlow RIVER Pro

Summary of Contents for EcoFlow RIVER Pro

  • Page 1 User Guide EcoFlow RIVER Pro 1. Keep EcoFlow RIVER Pro (hereinafter referred to as RIVER Pro) and the accessories dry and do not expose them to high heat. 2. Never disassemble, puncture, shock, crash, or incinerate the product. 3. Recycle and dispose of RIVER Pro in accordance with the local regulations.
  • Page 2 3. Never install or remove other modules from the RIVER Pro when it is turned on. Do Not plug or unplug other modules when the power of the product is turned on, otherwise the power interface may be damaged.
  • Page 3 2. If the product is not used for a long time, the battery life may be reduced. 3. Discharge EcoFlow RIVER Pro to 30%, then charge to 85% every 3 months to keep the battery healthy. Travel Notice: Do Not bring this product on flights.
  • Page 4 NOTICE To turn RIVER Pro on or off, you need to PRESS and HOLD the ON/OFF system Power Button. To turn on the AC power outlet, you need to PRESS and HOLD the AC Button after turning on RIVER Pro. We set the AC power button for users to turn off AC power when they don’t need it and save power.

  • Page 5: Table Of Contents

    EcoFlow App Download Guide Features of the RIVER Pro LCD Display Introduction Solar Panel Connection Entry-Level UPS AC X-Boost Mode RIVER Pro and RIVER Pro Extra Battery Connection Technical Specifications How to Recharge RIVER Pro FAQs What’s in the Box...

  • Page 6: Ecoflow App Download Guide

    EcoFlow App Download Guide 1. Download the EcoFlow App Search “EcoFlow” in the Google Play Store or App Store to download the App. You may also use your mobile phone to scan this QR code or enter the download link in your browser : https://ecoflow.com/pages/ecoflow-app...

  • Page 7: Features Of The River Pro

    14. Solar Charge/Car Charge Input Port 15. Power Earth Screw 16. Expansion Power Port 220-240V region*Dedicated AC Output *EcoFlow has designed different AC output sockets following the local regulations of different countries. 1. LCD Display Displays various conditions of the product.
  • Page 8 AC power. Make sure to unplug the power cord from the AC port. When the AC power of the RIVER Pro is enabled, the AC indicator will light up. If the AC power is not used for more than 12 hours, the AC ports will turn off automatically.

  • Page 9: Lcd Display Introduction

    RIVER Pro grounded using a grounding cable. 16. Expansion Power Port Plug in the Expansion Power Cable into this port to connect your RIVER Pro to a RIVER Pro Extra Battery to expand the battery capacity to 1440Wh.
  • Page 10 Low Temperature Indicator When the temperature of the RIVER Pro is too low, a low-temperature warning icon appears on the screen to warn that the temperature of the product is too low. Please warm up the product properly before use.
  • Page 11 Protection Information Instruction The RIVER Pro display screen uses different icons and combined icons to indicate the reason for device protection. USB-A and OVERLOAD icons flash together. USB-A Overload Disconnect all electrical appliances and wait 10 Protection seconds before adding each appliance back.
  • Page 12 OFF . It will automatically resume operation. The AC and Low-Temperature icons flash together. Inverter Low Temperture Move RIVER Pro to a warmer place and wait for the Protection inverter to warm up. Press AC Power ON/OFF button again. It will automatically recover.

  • Page 13: Solar Panel Connection

    If you need to know more about the connection of solar panel, please refer to the Solar Panel User Guide. Here we focus on demonstrate how to connect RIVER Pro to 1 set of solar panel or connect RIVER Pro to 2 sets of solar panels in parallel.

  • Page 14: Entry-Level Ups

    Entry-level UPS function. RIVER Pro's X-Stream system supports an entry-level UPS function. You can use the RIVER Pro AC socket while the device is connected to a wall socket with AC power supply (the AC power comes from the grid, not the battery). When the grid loses power suddenly, the device can automatically switch to be powered by RIVER Pro in <30ms.

  • Page 15: Ac X-Boost Mode

    600W-1200W electrical appliances. Please take note of the following when using this mode: 1. The X-Boost mode is enabled by default. You can use the EcoFlow app to turn this function on/off. Please do not connect the AC output to grid power when the X-Boost mode is on, doing so will activate the low-volt- age protection of the power station;...

  • Page 16: River Pro And River Pro Extra Battery Connection

    Expansion Power Cable to the port. Tighten the screws on both sides of the port to secure the connection. 3. Turn on the power button of RIVER Pro or RIVER Pro Extra Battery. If the display of RIVER Pro shows the Ex- tra Battery icon, the connection is successful.

  • Page 17: Technical Specifications

    Technical Specifications General Specs Net Weight * 15.9 lbs (7.2kg) Dimensions * 11.4 x 7.1 x 9.3 in (28.9 x 18.0 x 23.5 cm) Capacity 720Wh (28.8V) Testing and certification UL Standard, CE, FCC, RoHS Outputs 600W (Surge 1200W) total, 120Vac (50Hz/60Hz) / AC Output (x3) / (x2 International Version) Full Sine Wave 230Vac (50Hz/60Hz)

  • Page 18: How To Recharge River Pro

    How do I recharge my RIVER Pro? RIVER Pro has an AC charging port and an XT60 charging port located on the side of RIVER Pro. The RIV- ER Pro can be charged via AC power, 12V car charger or solar panels.

  • Page 19: Faqs

    How do I store RIVER Pro? Please store RIVER Pro in a dry and cool place. DO NOT place it near water. If you need to store RIVER Pro for a long time, Please discharge RIVER Pro to 30%, then charge to 85% every 3 month, in order to extend battery life.
