User Guide
EcoFlow RIVER
Extra Battery
WARNING
1. Please keep the EcoFlow RIVER Extra Battery (hereinafter referred
to as RIVER Extra Battery) dry. DO NOT expose it to high heat. Pay
attention to all safety instructions when carrying the product.
2. Never disassemble, puncture, shock, crash, or incinerate the
product or the accessories.
3. After removing the package, the Extra Battery must be installed
with RIVER as soon as possible. Please pay attention to static
electricity during the installation process.
4. Recycle and dispose of RIVER Max in accordance with local laws
and regulations.
5. People living with disabilities or children should use the product
under the guidance of the supervisor.
Advertisement
Related Manuals for EcoFlow RIVER
Summary of Contents for EcoFlow RIVER
- Page 1 Extra Battery 1. Please keep the EcoFlow RIVER Extra Battery (hereinafter referred to as RIVER Extra Battery) dry. DO NOT expose it to high heat. Pay attention to all safety instructions when carrying the product. 2. Never disassemble, puncture, shock, crash, or incinerate the product or the accessories.
- Page 2 Failure to operate the product correctly may result in damage to the product or personal property and cause serious injury. EcoFlow will not assume any legal responsibility. DO NOT use the product with incompatible components or alter the product in any way without following the instructions provided by EcoFlow.
- Page 3 Installation Notes: 1. The Extra Battery must be installed with RIVER before it can be used. It cannot be used by itself. 2. During the installation process, please pay attention to anti-static protection to ensure that there is no static electricity from the operator or the environment. Static electricity may cause damage to the product.
- Page 4 Product Charging 1. Always use EcoFlow approved charging cables. EcoFlow does not take any responsibility for any damages caused by using non-EcoFlow charging cables. 2. When charging, please place the product on the ground with no flammable or combustible materials around it.
-
Page 5: Table Of Contents
CONTENTS Extra Battery Usage and Safety Guide Extra Battery Installation Instructions Ambient Light Technical Specifications What’s in the Box... -
Page 6: Extra Battery Usage And Safety Guide
Users are recommended to purchase RIVER and the Extra Battery at the same time. If users purchase the Extra Battery after using the RIVER for a long time, the output of the product will be affected by the balance between the power station and the Extra Battery (normal process). Please fully charge the product to 100% before using it. -
Page 7: Extra Battery Installation Instructions
Ambient light and signal indication 1. Female Battery Socket And Installation Instructions 1. Make sure that the RIVER is turned off. Take out the screwdriver from the Extra Battery Module Kit and locate the four screws on the bottom cover. - Page 8 Male battery socket Short screws 2. Unscrew the four short screws according to the figure above before removing the bot- tom cover. The Male Battery Socket will be visible. Position the Extra Battery according to the figure below. (Note: Do not remove the top cover; only the bottom covers needs removing).
- Page 9 Long screws 3. Align the male and female battery sockets and connect them. Close the bottom cover. Take the four long screws from the Extra Battery Module Kit and screw them se- curely into place. power a free life...
- Page 10 4. Turn the RIVER upright and turn it on. The Extra Battery Panel will turn blue. The Extra Battery Indicator will be shown on the RIVER display when it has been installed correctly. Make sure the product is fully charged before use. If the ambient light does not turn on, or the Extra Battery Indicator does not show on the RIVER display, repeat Step 2 and check the product connection.
-
Page 11: Ambient Light
Charging: The blue light will move from left to right of the panel, repeatedly. 2. Customizing the Ambient Light Enter the Module Settings on the EcoFlow app to access ambient light features. 1. The ambient light can be turned on / off, kept on, or put on a standby mode. -
Page 12: Technical Specifications
Technical Specifications General Specs Net Weight 5.5lbs (2.5kg) Dimensions 11.2 x 7 x 2.3in (28.5 x 18 x 5.9cm) Capacity 288Wh (28.8V) Testing and certification UL Standard, CE, FCC, RoHS Battery Cell Chemistry Lithium-ion Discharge Temperature* -4°F to 140°F (±5°F), -20°C to 60°C (±3°C) Charge Temperature* 32°F to 113°F (±5°F), 0 to 45°C (±3°C) Shelf Life...
