ANTENNAS
Chapter 4 – Antennas
Antenna System Cellular Devices
The antenna system is defined as the U.FL connection point from the device through the cable and antenna.
Device performance depends on implementation and antenna system design. Integrating the antenna system is a
critical part of the design process; therefore, it is essential to consider it early so the performance is not
compromised.
Requirements for Cellular Antennas with regard to FCC/IC Compliance
The antenna must be the same type, with similar performance and in- and out-of-band radiation patterns as the
listed antenna. The antenna used must stay below the FCC/IC maximum gain.
For our bundles, MultiTech may change antennas over time. The listed antenna(s) is used as a reference or was
shipping when this document was last updated.
Antenna
Devices were approved with the following antenna:
Manufacturer:
Description:
Model Number
MultiTech ordering information:
Model
ANLTE4-1HRA
ANLTE4-2HRA
ANLTE4-10HRA
ANLTE4-50HRA
Antenna Specifications
Category
Frequency Range
VSWR
Gain
Impedance
Radiation
Polarization
16
Wieson
LTE Antenna with SMA-Male Connector
GY115IE002-001
Quantity
1
2
10
50
Description
0.698 - 0.96 GHz
1.710 - 2.170 GHz
2.30 - 2.69 GHz
3:1 maximum
2.06 dBi
50Ω nominal
Omni-directional
Linear, vertical
®
SocketModem
Cell MTSMC-L4E1 Device Guide for Europe
