INSTALLATION MANUAL
Ledgeview Fronts 546
Approved for use with Valor heater models 530 and 530 insert only
For Zero Clearance applications use 546LF_ZC
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and must be
installed for the protection of children and other at-risk
individuals.
The Ledgeview Fronts black 546LFB,
nickel 546LFN, bronze 546LFZ and pewter
546LFPW are designed to be installed on
the Valor Portrait 530 heater model in
insert applications.
Use the 546LF_ZC for zero clearance
applications.
4005277-05
©2020, Miles Industries Ltd.
Portrait
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Overview
INSTALLER: Leave this
manual with the appliance.
CONSUMER: Retain this
manual for future reference.
Note: This kit must be
installed or serviced by a
qualified installer, service
agency or gas supplier.
These instructions are to be
used in conjunction with the
main installation instructions
for the above listed heater
model.
Heat exchanger
cover
Roof grille
Ledgeview front assembly with Barrier screen
(530I sold separately)
Bridging baffle
530 Engine
Backing frame assembly
Backing plate

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 546LFB and is the answer not in the manual?

Questions and answers

Related Manuals for Valor 546LFB

Summary of Contents for Valor 546LFB

  • Page 1 INSTALLATION MANUAL Portrait Ledgeview Fronts 546 Approved for use with Valor heater models 530 and 530 insert only For Zero Clearance applications use 546LF_ZC DANGER INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this HOT GLASS WILL manual for future reference.

  • Page 2: Kit Contents

    Kit Contents Heat exchanger Bridging baffle cover • 1 Backing frame assembly Roof grille • 1 Backing plate • 1 Ledgeview front assembly • 1 Roof grille • 1 Heat exchanger cover • 1 Bridging baffle • 1 Barrier screen (fitted) •...

  • Page 3: Mantel Clearances

    Insert dimensions for 3 engine configurations These dimensions are for non-combustible installations 20” Mantel Clearances 0–6” 8” 10” 12” Mantel Depth ‘A’ (0–152 mm) (203 mm) (254 mm) (305 mm) 4” 8” 10” 12” Mantel Height ‘B’ (102 mm) (203 mm) (254 mm) (305 mm) 2”...

  • Page 4: Installation

    Installation b. Raise the grille up to cover the top firebox ports and hold with one hand. 1. Fit Bridging Baffle under the top panel of the Note: The port cover strip supplied with the appliance case. Secure as shown with 2 thread heater is not required.
  • Page 5 Cleaning 5. Locate into place the heat exchanger cover; note its shape and orientation to be as shown below.  WARNING DO NOT TOUCH the barrier screen, front or glass while they are hot! Let the fireplace cool first before cleaning it. To clean the barrier screen and the metal front use a soft brush.

  • Page 6: Repair Parts List

    Repair Parts List Description 546LFB 546LFN 546LFZ 546LFPW black nickel bronze pewter Backing Plate 4005098AZ 4005098AZ 4005098AZ 4005098AZ Backing Frame Assembly 4005104AZ 4005104AZ 4005104AZ 4005104AZ Bridging Baffl e 4005218BY 4005218BY 4005218BY 4005218BY Ledgeview Front Assembly 4005096AZ 4005096N 4005096BR 4005096PW Heat Exchanger Cover...

  • Page 7: Directives D'installation

    DIRECTIVES D’INSTALLATION Portrait Devanture Ledgeview 546 Certifi ée pour usage avec foyers Valor 530 et 530 encastrable seulement Pour applications à dégagement zéro utilisez le modèle 546LF_ZC DANGER INSTALLATEUR : Laissez cette notice avec l’appareil. CONSOMMATEUR : Conservez cette notice pour consultation VITRE CHAUDE - RISQUE ultérieure.

  • Page 8: Contenu Du Kit

    Contenu du kit Couvercle d’échangeur de chaleur Déflecteur Grille d’orifices • 1 Support de plaque de finition • 1 Plaque de finition • 1 Devanture Ledgeview • 1 Grille d’orifices • 1 Couvercle d’échangeur de chaleur • 1 Déflecteur • 1 Pare-étincelles (fixé à la devanture) •...
  • Page 9 Dimensions pour encastrables - 3 installations possibles Ces dimensions ne s’appliquent qu’aux installations dans des foyers incombustibles 20 [508] Dégagement minimum de ‘A’ 2 [51] au mur de côté Manteau Dégagement minimum de 2 [51] au mur de côté 1-1/16 [27] 6-7/8 ‘B’...
  • Page 10 Installation Au moment d’installer les panneaux intérieurs de céramique ou de verre, installez la grille d’orifices 1. Placez le déflecteur sous la paroi de la caisse du fournie avec la devanture Ledgeview comme suit : foyer. Fixez-le avec deux vis autotaraudeuse fournies. a.

  • Page 11: Entretien

    4. Placez la plaque de finition contre le support et fixez- 6. Accrochez la devanture Ledgeview munie du pare- la avec neuf vis fournies. étincelles à la plaque de finition. Note : Comme la peinture est appliquée à la plaque de finition de façon automatisée et que la plaque est symétrique.

  • Page 12: Liste De Pièces

    Liste de pièces Description 546LFB 546LFN 546LFZ 546LFPW noire nickel bronze étain Plaque de fi nition 4005098AZ 4005098AZ 4005098AZ 4005098AZ Support de plaque de fi nition 4005104AZ 4005104AZ 4005104AZ 4005104AZ Défl ecteur 4005218BY 4005218BY 4005218BY 4005218BY Devanture Ledgeview 4005096AZ 4005096N...
