Parts List - Linear Technology DC1816B Demo Manual

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C3
4 1 C6
5 1 C7
6 1 C8
7 1 C9
8 2 C10, C11
9 1 C13
10 1 C20
11 1 C21
12 4 D1, D2, D3, D4
13 2 D5, D6
14 1 D7
15 1 D8
16 1 D9
17 1 F1
18 2 L1,L2
19 1 L3
20 1 Q1
21 2 R1, R2
22 2 R3, R18
23 1 R4
24 1 R5
25 1 R6
26 1 R7
27 1 R8
28 1 R9
29 2 R10, R11
30 1 R12
31 1 R19
32 1 R20
33 1 R21
34 1 R25
35 1 T1
36 1 U1
37 1 V1
38 1 Z2
39 1 Z3
40 1 Z4
PART DESCRIPTION
CAP, 0.47µF 20% 310V POLYPROPYLENE
CAP, 0.47µF 20% 450V FILM
CAP, 22µF 20% 35V ALUM
CAP, 0603 10nF 10% 50V X7R
CAP, 0603 0.1µF 10% 50V X7R
CAP, 0805 4.7µF 20% 16V X5R
CAP, 2220 10µF 20% 100V X7S
CAP, 1000µF 20% 63V ELEC
CAP, 1210 2.2nF 5% 630V U2J
CAP, 2.2nF 10% Y5B TYPE "Y1"
CAP, 0603 4.7pF ±0.1pF 50V NP0
DIODES, RECTIFIER 1.0A
DIODE, FAST SWITCHING
DIODE, ULTRA FAST RECOVERY SILICON RECTIFIER
DIODE, SUPER BARRIER RECTIFIER 10A
DIODE, RECOVERY RECTIFIER
FUSE, FAST ACTING 3.15A
IND, 10mH COMMON MODE CHOKE
IND, 150µH LINE CHOKE
XSTR, COOL MOS POWER TRANSISTOR
RES, 1206 249k 1% 1/4W
RES, 0603 100k 5% 1/10W
RES, 0603 4.32k 1% 1/10W
RES, 0603 20Ω 5% 1/10W
RES, 2512 200k 5% 1W
RES, 0603 2k 5% 1/10W
RES, 1206 0.015Ω 1% 1/4W
RES, 1206 10k 1% 1/4W
RES, 1206 499k 1% 1/4W
RES, 0603 3.09k 1% 1/10W
RES, 0603 40.2k 1% 1/10W
RES, 0603 16.9k 1% 1/10W
RES, 0603 0Ω JUMPER
RES, 0603 17.8Ω 1% 1/10W
XFMR, FLYBACK
IC, OFFLINE ISOLATED LED CONTROLLER
VARISTOR, 385V RMS 13.5MM RADIAL
DIODE, TRANSIENT VOLTAGE SUPPRESSOR
DIODE, TRANSIENT VOLTAGE SUPPRESSOR
DIODE, TRANSIENT VOLTAGE SUPPRESSOR
DEMO MANUAL DC1816B
MANUFACTURER/PART NUMBER
VISHAY BFC33820474
RUBYCON 450MMK474K
NIC NRSZ220M35V5X11F
AVX 06035C103KAT2A
AVX 06035C104KAT2A
AVX 0805YD475MAT2A
TDK C5750X7S2A106M
PANASONIC EEU-FC1J102
MURATA GRM32A7U2J222JW31D
VISHAY 440LD22-R
AVX 06035A4R7CAT2A
DIODES INC. 1N4005-T
DIODES INC. BAV20W-7-F
CENTRAL SEMI.CMR1U-10M
DIODES INC. SBR10U300CT
CENTRAL SEMI.CMR1U-02M
BUSSMAN SS-5H-3.15A-APH
SUMIDA LF2628NP-103
WÜRTH ELECTRONIK 7447018
INFINEON SPP17N80C3
VISHAY CRCW1206249KFKEA
VISHAY CRCW0603100KJNEA
VISHAY CRCW06034K32FKEA
VISHAY CRCW060320R0JNEA
VISHAY CRCW2512200KJNEG
VISHAY CRCW06032K00JNEA
VISHAY WSL1206R0150FEA
VISHAY CRCW120610K0FKEA
VISHAY CRCW1206499KFKEA
VISHAY CRCW06033K09FKEA
NIC NRC06F4222TRF
VISHAY CRCW060316K9FKEA
VISHAY CRCW06030000Z0EA
VISHAY CRCW060317R8FKEA
WÜRTH ELECTONIK 750811351
LINEAR TECH. LT3799EMSE-1
SEI CV385K10B
DIODES INC. SMBJ130(C)A-13-F
DIODES INC. SMCJ40(C)A-13-F
LITTELFUSE INC. SMCJ220CA
