DEMO MANUAL DC1816B
parts List
ITEM QTY REFERENCE
Additional Demo Board Circuit Components
1 0 C14
2 0 D10
3 0 R13
4 0 R22
Hardware—For Demo Board Only
1 2 HS1, HS2
2 2 J1, J2
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 1
6
PART DESCRIPTION
CAP, 1206 100pF 5% 1000V U2J
DIODE, ULTRA FAST RECOVERY SILICON RECTIFIER
RES, 1206 10k 1% 1/2W
RES, 0603
HEAT SINK, TO-220
TERMINAL BLOCK, 2 POSITION
NUT, TIN PLATE#4-40
WASHER, #4, FLAT WASHER
SCREW, 4/40 X 3/8
NUT, TIN PLATE# 2-56
WASHER, #2, FLAT WASHER
SPACER, NYLON SHOULDER
SCREW, 2-56 X 3/8
THERMAL PAD
SILICONE HEAT SINK
FAB, PRINTED CIRCUIT BOARD
STENCIL
MANUFACTURER/PART NUMBER
MURATA GRM31A7U3A101JW31D
CENTRAL SEMI. CMR1U-10M
VISHAY CRCW120610K0JNEAHP
AAVID THERMALLOY 529802B02500G
WEIDMULLER 1715250000
ANY, #4-40
ANY
ANY, 4/40 X 3/8, PHILIPS SCREW
ANY, #2-56
ANY
KEYSTONE, 3051
ANY, 2-56 X 3/8 PHILIPS SCREW
BERGQUIST, SP600-58
RAWN
DEMO CIRCUIT 1816B
STENCIL DC1816B
dc1816bfc
