Service Manual
Digital Displacement® Pump DDP096

Required tools

Mechanical tools

Electrical tools

Additional tools

© Danfoss | April 2022
This list shows the required tools to disassemble/assemble the pump.
•
Snap-ring pliers (suitable for 58 mm internal circlips)
•
Cable tie cutters
•
Cable tie tensioner and cutter (optional)
•
3 mm hex key
•
19 mm hex wrench with deep socket
•
22 mm hex wrench (deep socket recommended)
•
Phoenix Contact torque screwdriver – TSD 04 SAC (Phoenix Contact part number: 1208429)
•
Phoenix Contact tool – SACC BIT M12-D20 (Phoenix Contact part number: 1208445)
•
Appropriate torque wrenches (see
This list contains tools needed for testing electrical components of the pump.
•
Multimeter
This list contains tools or other objects for the maintenance of the pump that are not categorically
mechanical or electrical.
•
Thread sealant Loctite 243 or similar thread locking compound
•
Pump stand
For most of the minor repairs, it is recommended to mount and secure the DDP096 to a 4-bolt SAE C
stand in a horizontal position or in a vertical position with the input shaft pointing downwards (with a
minimum ground clearance of 80 mm).
Fasteners and torque)
AX398964822217en-000101 | 9
