Instructions
U-LGPS
LED and LDP Light Source
This instruction manual is for the Olympus LED and LDP Light Source.
To ensure safety, obtain optimum performance and to familiarize yourself fully with the use of this
product, we recommend that you study this manual thoroughly before operating this product, and
always keep this manual at hand when operating this product.
Optical Microscope Accessory
Retain this instruction manual in an easily accessible place near the work desk for future reference.
For details of products covered by this instruction manual, see page 10.
Advertisement
Table of Contents
Related Manuals for Olympus U-LGPS
Summary of Contents for Olympus U-LGPS
- Page 1 U-LGPS LED and LDP Light Source This instruction manual is for the Olympus LED and LDP Light Source. To ensure safety, obtain optimum performance and to familiarize yourself fully with the use of this product, we recommend that you study this manual thoroughly before operating this product, and always keep this manual at hand when operating this product.
- Page 2 In accordance with European Directive on Waste Electrical and Electronic Equipment, this symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be collected separately. Refer to your local Olympus distributor in EU for return and/or collection systems available in your country. For Korea only For Korea only 이...
-
Page 3: Table Of Contents
U-LGPS Contents Concept of this instruction manual ..................... 1 Product Concept ............................2 Safety precautions ............................3 Handling precautions..........................7 List of combinable systems ....................... 8 Maintenance and Storage ........................9 1 Nomenclature of main operating portions ..............10 2 Operating Procedures ........................11 Turning ON the lamp ................................ -
Page 5: Concept Of This Instruction Manual
When using this product, read all the instruction manuals supplied with the units you purchased together with this manual. Applicable user of this instruction manual This instruction manual applies to users who use this product according to "Intended use" and Olympus distributors. How to read this instruction manual This instruction manual is created as follows. -
Page 6: Product Concept
Product Concept Product outline U-LGPS (LED and LDP Light Source) is a light source used for observing a sample in combination with the microscope. Intended Use This product is used for research, industrial and in vitro diagnostic medical purposes in combination with microscopes. -
Page 7: Safety Precautions
Laser safety · Never peel off the warning label. CAUTION Warning label position: Right side surface of U-LGPS This product is specified as CLASS 1 laser product. CLASS 1 LASER PRODUCT (IEC60825-1:2007 / IEC60825-1:2014) This product complies with 21 CFR 1040.10 and 1040.11 except for conformance with IEC 60825-1 Ed. - Page 8 · Do not connect or disconnect the power cord, cables and units while the power is on. · Always use the USB cable provided by Olympus. If you connect the USB cable that is not provided by Olympus, U-LGPS may not work properly.
- Page 9 14. · Do not remove the liquid light guide when the lamp is turned ON. The light emitted from U-LGPS may cause a fire. In addition, you may get burned or your eyes may be damaged. Remove the liquid light guide after the liquid light guide and the LDP light source are fully cooled CAUTION down.
- Page 10 OFF side.) Indicates that the seesaw type main switch is OFF. If caution labels are dirty or peeled off, contact Olympus for replacement or inquiries. Label position and instruction The labels are attached to the portions which require special cautions during use and operation. Be sure to follow these instructions.
-
Page 11: Handling Precautions
· Avoid twisting the U-LGPS as much as possible to prevent damage. Also, do not pull it forcibly with a tension of 3 kg or more. -
Page 12: List Of Combinable Systems
List of combinable systems This section indicates systems that can be combined with this product. Standard IEC60825-1 System Microscope frame JIS C6802 IEC62471-1 GB7247 FDA 21CFR Part 1040.10 and 1040.11 BX43 BX43F BX53 BX53F BX53F2 BX63 BX63F CKX53 CKX53SF IX73 IX73P1F IX73P2F IX83... -
Page 13: Maintenance And Storage
· Blow off the dust attached to the edge surface of the liquid light guide with clean air. Cautions after use · After using this product, set the main switch of U-LGPS to (OFF), wait until U-LGPS is cooled down sufficiently, and keep it covered with a dust cover during storage. -
Page 14: Nomenclature Of Main Operating Portions
Nomenclature of main operating portions This section describes the nomenclature of main operating portions of U-LGPS, U-LLG150/U-LLG300 and U-LLGAD. LED and LDP Light Source U-LGPS Liquid light guide insertion port Counter Light intensity Light intensity adjustment dial adjustment dial Lamp switch... -
Page 15: Operating Procedures
U-LGPS control software. Press the lamp switch C on the front of U-LGPS. · The color of the pilot lamp B on the front of U-LGPS turns to blue. · Pressing the lamp switch C allows you to select ON or OFF of the lamp. -
Page 16: Adjusting The Brightness
When using U-LGPS control software: · You cannot adjust the light intensity using the light intensity adjustment dial E . Adjust the light intensity on the U-LGPS control software. Pilot lamp color and counter display The relation between the color of the pilot lamp B and the display on the counter D are listed as follows. -
Page 17: Troubleshooting
Repair request If you cannot solve the problems even though taking actions described in Troubleshooting, please contact Olympus for assistance. At that time, please tell them the following information as well. · Product name and abbreviation (Example: U-LGPS) ·... -
Page 18: Specifications
Power consumption 180 W or less Current consumption 2.2 A / 1.0 A Response time 60 ms Condition specified by Olympus I/O connector USB (B-type) Dimension / Weight 120 (W) x 335 (D) x 214 (H) mm (excluding protrusions) 4.9 kg... -
Page 19: Assembly
Attach U-LLGAD to the illuminator. Tighten the clamping screw E of the illuminator using the Allen screwdriver provided with the microscope. Do not turn ON the lamp while U-LGPS is not attached to WARNING the microscope using U-LLG150/U-LLG300 and U-LLGAD. -
Page 20: Attaching The Power Cord
Attaching the power cord · Always use the power cord provided by Olympus. If the CAUTION proper power cord is not used, the electric safety and the EMC (Electromagnetic Compatibility) performance of the product cannot be assured. If no power cord is provided, please select the proper power cord by referring to the section “Proper selection of the power cord”... -
Page 21: Replacing The Fuse
Using a non-specified fuse may cause a fire. WARNING Return the fuse box to the original position, and rotate the fuse box B using the flat-blade screwdriver to secure it. If the fuse is blown out frequently, contact Olympus for assistance. - Page 22 If no power supply cord is provided, please select the proper power supply cord for the equipment by referring to “Specifications” and “Certified Cord” below: Caution : In case you use a non-approved power supply cord for Olympus products, Olympus can no longer warrant the electrical safety of the equipment.
- Page 23 U-LGPS Table 2 HAR flexible cord Approval organizations and cordage harmonization marking methods Alternative marking utilizing Printed or embossed black-red-yellow thread (Length harmonization marking (May be of color section in mm) Approval organization located on jacket or insulation of internal wiring)
- Page 24 Manufactured by Shinjuku Monolith, 2-3-1 Nishi-Shinjuku, Shinjuku-ku, Tokyo 163-0914, Japan Distributed by AM5103 01 Issued in September, 2020...
