This instruction manual is for the Olympus Coded Function System. To ensure the safety, obtain optimum
performance and to familiarize yourself fully with the use of this system, we recommend that you
study this manual and the manuals of units used in combination with this system thoroughly before
operating the system.
Retain this instruction manual in an easily accessible place near the work desk for future reference.
CODED FUNCTION SYSTEM
INSTRUCTIONS
A X 7 8 7 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the U-D7RES and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus U-D7RES

Summary of Contents for Olympus U-D7RES

  • Page 1 U-CBS CODED FUNCTION SYSTEM This instruction manual is for the Olympus Coded Function System. To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of this system, we recommend that you study this manual and the manuals of units used in combination with this system thoroughly before operating the system.
  • Page 2 In accordance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment, this symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be collected separately. Refer to your local Olympus distributor in EU for return and/or collection systems available in your country.

  • Page 3: Table Of Contents

    CODED FUNCTION SYSTEM CONTENTS Page IMPORTANT — Be sure to read this section for safe use of the equipment. — 1 CONNECTOR NOMENCLATURE 2 SYSTEM CHART 3 CABLE DISTRIBUTIONS BX43 (System with LED Lamp Housing) ................................7 BX43 (System with Halogen Lamp Socket)..............................8 BX53 System .................................................

  • Page 4: Important - Be Sure To Read This Section For Safe Use Of The Equipment

    IMPORTANT This system is capable of reading coded information from the BX3-RFAS Fluorescence Illuminator and the U-D7RES 7-Position Revolving Nosepiece and transmitting the information externally. SAFETY PRECAUTIONS 1. Before connecting the cables, make sure that the POWER switch of the U-CBS control box is set to OFF (out position).
  • Page 5 CODED FUNCTION SYSTEM Getting Ready 1. This system is composed of precision instruments. Handle it with care and connect cables gently to avoid subjecting it to sudden or severe impact. 2. Do not use the system where it is subjected to direct sunlight, high temperature and humidity, dust or vibrations. 3.

  • Page 6: Connector Nomenclature

    CONNECTOR NOMENCLATURE Control Box for Coded Function U-CBS Microscope frame hangers (top/bottom) U-D7RES connector RS-232C connector BX3-RFAS connector Option connector The U-CBM can be connected. U-HSEXP connector For the external DP21 exposure button. POWER switch ON: Depressed position. OFF: Out position.

  • Page 7: System Chart

    The connectors of the U-CBS are sealed with dust covers. Remove the dust covers only from the connectors you want to connect cables. · Be sure to connect the module designated by Olympus to each connector. If a non-designated module is connected, the performance of the entire system cannot be guaranteed.
  • Page 8 ON in the order of: @ U-CBS and 2 DP21-CB. Otherwise, the DP21 will not recognize the U-CBS. Also if the U-D7RES is not connected to the U-CBS, the DP21 will not recognize it either. So be careful.

  • Page 9: Cable Distributions

    } The cables can be laid properly by attaching the cable holders provided with each module (6 cable holders are provided with the U-CBS control box, 2 with the U-D7RES revolving nosepiece and 1 with the U-LS30AD adapter) on the rear panel of the microscope frame.

  • Page 10: Bx43 (System With Led Lamp Housing)

    BX43 (System with LED Lamp Housing U-LHLEDC) BX3-RFAS cable U-D7RES cable Use 6 cable holders. RS-232C cable Align with the top right Align with the top left corner of the label. corner of the label. U-HSEXP cable for U-HSEXP cable for...

  • Page 11: Bx43 (System With Halogen Lamp Socket)

    CODED FUNCTION SYSTEM BX43 (System with Halogen Lamp Socket U-LSADP + U-LS30-5) BX3-RFAS cable U-D7RES cable U-HSEXP cable for right side installation RS-232C cable Use 6 cable holders. Align with the top right corner of the label. Align with the top left corner of the label.

  • Page 12: Bx53 System

    BX53 System U-D7RES cable BX3-RFAS cable Approx. 10 mm Align with the top left corner of the label. RS-232C cable U-HSEXP cable for Align with the top right right side installation corner of the label. Align with the top of the lamp housing connector.

  • Page 13: Readout/External Transmission Of Coded Information

    CODED FUNCTION SYSTEM READOUT/EXTERNAL TRANSMISSION OF CODED INFORMATION } This system makes it possible to acquire the information on the objective positions of the U-D7RES revolving nosepiece and that on the mirror unit positions of the BX3-RFAS fluorescence illuminator. The acquired information can be transmitted to the DP21 microscope digital camera through the RS-232C cable.
  • Page 14 U-HSEXP. · PC · Mobile phone · Clock/watch · Credit card · Bank card · Floppy disk, etc. } Unless the U-D7RES is connected to the U-CBS, the U-HSEXP does not function. So be careful.
