INSTRUCTIONS
U-AW
MOTORIZED ATTENUATOR WHEEL
This instruction manual is for the Olympus Motorized Attenuator Wheel Model U-AW.
To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of this
Optical Microscope Accessory
motorized attenuator wheel, we recommend that you study this manual thoroughly before operating
the microscope.
Retain this instruction manual in an easily accessible place near the work desk for future reference.
A X 8 2 4 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-AW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Olympus U-AW

  • Page 1 INSTRUCTIONS U-AW MOTORIZED ATTENUATOR WHEEL This instruction manual is for the Olympus Motorized Attenuator Wheel Model U-AW. To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of this Optical Microscope Accessory motorized attenuator wheel, we recommend that you study this manual thoroughly before operating the microscope.
  • Page 2 In accordance with European Directive on Waste Electrical and Electronic Equipment, this symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be collected separately. Refer to your local Olympus distributor in EU for return and/or collection systems available in your country. For Korea only A급...
  • Page 3: Table Of Contents

    CONTENTS IMPORTANT -- Be sure to read this section for safe use of the equipment. -- SAFETY PRECAUTIONS ............................1 Handling Precautions..................................2 Maintenance and Storage ................................2 1 SYSTEM CHART ..........................2 ASSEMBLY ............................. Installation in a Reflected Light Illumination System ....................6 Installation in a Transmitted Light Illumination System..................8 3 OPERATION ............................
  • Page 5: Important

    Caution labels are placed at parts where special precaution is required when handling and using the system. Always pay attentions to the caution labels. Positions of caution · Motorized attenuator wheel [Caution against high temperature] labels (U-AW) If the caution label becomes dirty or is peeled off, contact Olympus for replacement.
  • Page 6: Handling Precautions

    Handling Precautions 1. This device is a precision instrument. Handle it with care and avoid subjecting it to sudden or severe impact. 2. Do not disassemble this system. Doing so could cause failure of the system. 3. Do not use the system where it is subjected to direct sunlight, high temperature and humidity, dust or vibrations. 4.
  • Page 7: System Chart

    U-AW SYSTEM CHART Extension adapter Reflected light for lamp housing lamp housing U-LHEAD U-LH100HG, U-LH100HGAPO, U-LH75XEAPO BX63 Motorized BX63 attenuator wheel U-AW Transmitted light lamp housing U-LH100-3 * U-LH100L-3, etc Motorized attenuator wheel U-AW Interface cable * LH100 adapter U-LH100ADP...
  • Page 8 IX83 Motorized attenuator wheel Transmitted light U-AW lamp housing U-LH100-3 * U-LH100L-3, etc IX83 Plate (Accessory of U-AW ) Reflected light Extension adapter for lamp housing lamp housing U-LHEAD U-LH100HG, U-LH100HGAPO, U-LH75XEAPO Motorized attenuator wheel U-AW Interface cable * Extension adapter...
  • Page 9 U-AW IX73 Motorized attenuator wheel Transmitted light U-AW lamp housing U-LH100-3 * U-LH100L-3, etc IX73 Plate (Accessory of U-AW ) Reflected light Extension adapter lamp housing for lamp housing U-LH100HG, U-LHEAD U-LH100HGAPO, U-LH75XEAPO Motorized attenuator wheel U-AW Extension adapter for lamp housing...
  • Page 10: Assembly

    Attach the U-AW d to the U-LHEAD (frame side), and tighten the clamping screws a . Loosen the clamping screws e (4 pcs.) of the U-AW, fit the U-LHEAD (lamp housing side) f and tighten the clamping screws e (upper 2 pcs. only).
  • Page 11 Attach the U-AW d to the U-LHEAD (frame side), and tighten the clamping screws a . Loosen the clamping screws e (4 pcs.) of the U-AW, fit the U-LHEAD (lamp housing side) f and tighten the clamping screws e (upper 2 pcs. only).
  • Page 12: Installation In A Transmitted Light Illumination System

    Attach the U-AW e to the U-LH100ADP [Front] and tighten the clamping screws a . Loosen the clamping screws f (4 pcs.) of the U-AW, fit the U-LH100ADP [Rear] g by aligning the positioning pin, and tighten the clamping screws f (upper 2 pcs. only).
  • Page 13 One for the frame displays [FRAME] and the other for the lamp housing displays [ Loosen the lamp housing clamping screw b (4 psc.) of the U-AW and insert the plate provided with U-AW into the adapter mounting area. Be sure to insert the plate by fitting its position so that the nail c of the plate enters in the dent d of the microswitch.
  • Page 14: Operation

    OPERATION The transmittance of the motorized attenuator wheel can be switched from the following modules. System Using the Control Box BX3-CBH · Touch-panel controller (provided with the BX63) · Controller U-MCZ System Using the Control Box U-CBM · Hand switch U-HSCBM for CBM System Using the Control Box IX3-CBH ·...
