Step 5. Fitting The Trim - Create WIND FOLD Manual

G
+
EMBELLISHER
1
Using a screwdriver, remove the 3 center screws from the
motor for later use. If these screws come in a sealed bag,
use them for this step.
4
G
place the piece G aligning
the holes with the holes in
the motor. Leave the blue
and white wires coming out
of the hole,
7

STEP 5. FITTING THE TRIM

N
+
SCREWS FOR
EMBELLISHER
2
5
Then firmly tighten the
screws used in step 1 so
that the part G is properly
fastened.
3
G
Pass the fan cables through
the center hole of the piece
G.
6
ENGLISH 19
