IT'S GOOD TO KNOW!

ST M3 2 F20 7 VGT6 i s t he d efau l t mi c ro c o n tr ol ler!
STM32F207VGT6 belongs to ARM®Cortex™-M3 family. It has 120MHz frequency, 1 Mbyte of Flash memory, 128K + 4K bytes of
general-purpose SRAM, integrated Ethernet controller, USB 2.0 (OTG, Host, Device), 83 General purpose I/O pins, 12x16-bit and
2x32-bit timers, 3x12-bit A/D (24 channels), 2x12-bit D/A , 4xUSARTs, 2xUARTs, internal Real time clock (RTC), 2xI2C, 3xSPI and
2xCAN controllers. It has Serial wire debug (SWD) and JTAG interfaces for programming and debugging.
SYSTEM SPECIFICATIONS
POWER SUPPLY
7–23V AC or 9–32V DC
or via USB cable (5V DC)
PACKAGE CONTAINS
1
Damage
resistant
protective
box
POWER CONSUMPTION
~76mA when all peripheral
modules are disconnected
2
EasyPIC v7a
development
board
BOARD DIMENSION
266 x 220 mm
(10.47 x 8.66 inch)
3
USB
cable
E a s y M x P R O v 7 a
BOARD WEIGHT
~500g
(1.1 lbs)
U s e r M a n u a l
