- Page 1 SMARTPAT COND 5200 Supplementary Instructions Digital conductivity sensor Category II 1 G EPL Ga © KROHNE 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en AD...
-
Page 2: Table Of Contents
5.1 Starting up for the first time ..................13 5.2 Operation ........................13 5.3 Electrostatic charge ....................... 13 6 Service 6.1 Maintenance ........................14 6.2 Dismantling ........................14 7 Notes www.krohne.com 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en... -
Page 3: Safety Instructions
Explosive Atmospheres acc. to IEC 60079-0:2018 and IEC 60079-11:2012 . The number of the IECEx certificate is: IECEx KIWA 14.0004X You can download the IECEx certificate from the official IECEx website www.iecex.com or from the manufacturer's website. 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en www.krohne.com... -
Page 4: Conformity
CAUTION! Operating conditions and place of installation may require compliance with additional standards, directives or laws. The responsibility for compliance rests solely with the operator or his agent. www.krohne.com 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en... -
Page 5: Device Description
The connection is designed as a plug connector and at the same time supplies the sensor with power. 1 VP 2.0 connector 2 PEEK housing 3 G3/4 A thread (male) or 3/4-14 NPT (male) 4 Electrodes: graphite, PES 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en www.krohne.com... -
Page 6: Marking
6 Serial number, D14xxxxxxx = Year of manufacture 2014 7 Ex data acc. to KIWA 14ATEX0002 X or IECEx KIWA 14.0004X or CSAE 21UKEX2617X 8 Manufacturing date / Ingress protection 9 Observe the installation and operating instructions www.krohne.com 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en... -
Page 7: Flammable Products
Operating conditions: The sensor part of SMARTPAT COND 5200 may operate outside the standard atmospheric pressure range, which means that explosion protection may not be applicable for the sensor part (piping). -
Page 8: Protection Type For Gas Hazardous Areas
• Insulation does not obstruct the ventilation of the sensor. INFORMATION! The sensor has several temperature class information due to different ambient temperature ranges. In principle, operation is possible in all ranges of the temperature classes T1...T6. www.krohne.com 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en... -
Page 9: Electrical Data
= 15.5 mA • P = 30.5 mW The connections for the intrinsically safe 4...20 mA sensor circuit are galvanically isolated from the electrode circuit (test voltage 500 V 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en www.krohne.com... -
Page 10: Installation
• For temperature data, refer to section 2.6 of this supplementary manual. • The Conductivity Sensor shall be installed in such a way that danger of electrostatic discharge is prevented. The equipment may only be cleaned with a wet cloth. www.krohne.com 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en... -
Page 11: Electrical Connections
The connector pin assignment of the sensor is described in the standard documentation. The signal circuits of the sensor may only be connected to certified intrinsically safe slave units or circuits. For more information refer to chapter "Electrical data". 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en www.krohne.com... -
Page 12: Grounding And Equipotential Bonding
(test voltage 500 V ). It is accepted that the electrode circuit can be directly connected to the ground potential. www.krohne.com 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en... -
Page 13: Operation
The sensors must not be cleaned using the dry method. The sensor housing is made from non-conductive PVDF. In order to avoid danger from electrostatic charge, the minimum conductivity of the media must be 10 nS/cm. 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en www.krohne.com... -
Page 14: Service
• If the process pipes or the container contain products that are harmful to the environment or to health, implement the appropriate safety measures before dismantling the sensor. • Replace all the seals when reinstalling the device in the process pipe or container. www.krohne.com 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en... -
Page 15: Notes
NOTES SMARTPAT COND 5200 03/2022 - 4004007703 - MA SMARTPAT COND 5200 R03 en www.krohne.com... - Page 16 Engineering, commissioning, calibration, maintenance and training services Head Office KROHNE Messtechnik GmbH Ludwig-Krohne-Str. 5 47058 Duisburg (Germany) Tel.: +49 203 301 0 Fax: +49 203 301 10389 info@krohne.de The current list of all KROHNE contacts and addresses can be found at: www.krohne.com...
