3. Description and operation

Description:
The SunBox consists of a mounted and wired cabinet prepared to include up to
2 Turbo Energy Lithium Batteries (Lithium Series 48V 5.1kWh) and a Turbo Energy
Single Phase Hybrid Series 48V 5.0.
The system includes several protections for both DC and AC:
Continuous current (DC)
Four 16A fuses
-
AC (Protections)
A magnetothermal switch
-
The machine has fast MC4 links that facilitate the connection of each string.
In terms of support and handling, the system includes four wheels that can
support a load of 280 Kg.
Operation mode:
The SunBox can work in Self-consumption mode and in Off-Grid mode, and for
this, the SunBox has a switch to toggle between both modes.
