Turbo Energy Lithium Slim Series Quick Installation Manual
48v 2.4 kwh + goodwe inverter
Hide thumbs
Also See for Lithium Slim Series:
- Instruction manual (13 pages) ,
- Quick installation manual (4 pages)
Related Manuals for Turbo Energy Lithium Slim Series
Summary of Contents for Turbo Energy Lithium Slim Series
- Page 1 Quick Installation Guide Lithium Series Slim 48V 2.4 kWh + Goodwe Inverter AÑOS TURBO ENERGY WARRANTY www.turbo-e.com...
- Page 2 1. Goodwe Inverter configuration (Wifi) First, the inverter must be configured properly. For this, a correct Wi-Fi connection must be made between the electronic device and the inverter, as well as a correct configuration through the PV Master application. To make a correct Wi-Fi connection, follow these steps: Note: This connection can also be made from the PV Master app.
- Page 3 2. Goodwe Inverter configuration (PV Máster) PV Master is an external monitoring / configuration application for hybrid inverters. It can be downloaded directly from the Play Store or App Store and works with both Android and iOS systems. Once it has been successfully connected to the inverter's Wi-Fi network, the application must be configured according to the batteries to be connected.
- Page 4 3. Battery configuration Each module has 4 DIP (Dual that will be configured differently Inline Package) switches depending on the number of batteries to be connected. 1=ON 0=OFF They are configured according to the binary code, starting with the master. Address Dial switch position Explain Pack1/Master...
- Page 5 4. Configuración CABLEADO The cable necessary to make the connection is the RJ45. It is a special cable that is made up of 8 smaller cables each with a different color configuration. It will be needed a PIN to PIN standar with RJ45 connector. Connect the cable to the CAN-1 battery port...
