Quick Installation Guide
Battery Lithium Series Slim
48V 2.4 kWh + Inverter Voltronic
www.turbo-e.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Battery Lithium Slim Series and is the answer not in the manual?

Questions and answers

Related Manuals for Turbo Energy Battery Lithium Slim Series

Summary of Contents for Turbo Energy Battery Lithium Slim Series

  • Page 1 Quick Installation Guide Battery Lithium Series Slim 48V 2.4 kWh + Inverter Voltronic www.turbo-e.com...
  • Page 2 1. INVERTER VOLTRONIC VMIII configuration In the Inverter menu it is necessary to change parameter 5 to the LIB configuration. 2. Battery configuration Each module has 4 DIP (Dual Inline Package) switches that will be configured differently depending on the number of batteries to be connected.
  • Page 3 Pack8 Pack9 Pack10 Pack11 Pack12 Pack13 Pack14 Pack15 Any changes to the DIPs must be made with the battery turned off. When the battery works by voltage, it is not necessary to communicate the batteries with each other or select a certain DIP configuration. 3.
  • Page 4 Each power cord can carry a maximum of 120 A, so every two batteries a new cable would need to be connected to the inverter. However, if the inverter is 5 kW with a cable it would be sufficient to be within the limit of the maximum recommended current.
