Figure A-2
Figure A-3
Operations Guide
shows a wall mounting option.
Figure A-2. Wall Mounting Option
Pre-Drill hole
on Wall (4x)
Drywall
Cutout
Earth Ground
Wire
Earth Ground Wire Connect to
Any Available Mounting Hole
shows a 1-Gang Box and a 2-Gang Box mounting option.
Figure A-3. Gang Box Mounting
Two
Gang Box
(Not Provided)
Earth Ground
Earth Ground Wire Connect to
Any Available Mounting Hole
930386E
Network
Cable
Through
Cable Entry Slot
Mounting Screws &
Plastic Anchors (4x)
Network
Cable
Backplate
Single
Gang Box
(Not Provided)
Drywall
Cutout
Network
Cable
Wire
Mount the Office Ringer
Cable Entry Cover
Rotate Backplate to Close
When Not Use
Cable Entry Slot
Drywall
Cutout
Gang Box
Mounting Screw
(4 Pieces Provided)
CyberData Corporation
60
