2.3.7 Configure the Sensor Configuration Parameters

The door sensor (pins 5 and 6) on the header can be used to monitor a door's open or closed state.
There is an option on the Sensor Configuration page to trigger on an open or short condition on
these pins. The door sensor alarm will be activated when the Door Open Timeout parameter has
been met.
The intrusion sensor is an optical sensor installed on the Office Ringer board and will be activated
when the Office Ringer is removed from the case.
For each sensor there are four actions the Office Ringer can take:
• Flash the LED until the sensor is deactivated (roughly 10 times/second)
• Activate the relay until the sensor is deactivated
• Loop an audio file out of the Office Ringer speaker until the sensor is deactivated
• Call a preset extension and play a pre-recorded audio file (once)
Note
Operations Guide
Calling a preset extension can be set up as a point-to-point call, but currently can't send
delayed DTMF tones.
