2.2 Office Ringer Setup

2.2.1 Office Ringer Connections

Figure 2-1
AWG gauge wire.
Note
Alternate Power Input:
1 = +5V at 1000 mA
2 = Power Ground
Relay Contact:
(1A at 30 VDC for Continuous Loads)
3 = Normally Open Common
4 = Normally Open Contact
5 = Door Sense Input
6 = Door Sense Ground Reference
Operations Guide
shows the pin connections on the J3 (terminal block). This terminal block can accept 16
As an alternative to using PoE power, you can supply 5 VDC at 1000 mA into the terminal
block.
Figure 2-1. Office Ringer Connections
Accept 16 AWG Gauge Wire
3
4
930386E
Installing the VoIP Indoor Office Ringer
J3
1
2
3
4
Terminal Block
5
6
CyberData Corporation
7
