PREPARING THE TABLE TOP FOR MOVING (SL only)

WARNING: Do not tilt the unit to the vertical position until the Table End Bracket is properly
installed (step 4 below).
Before the SL model can be tilted to vertical, you must slide the table to the left and clamp it so it
clears the floor when the unit is tilted to vertical. Do the following:
1. Remove the table top pad.
2. Remove the three Phillips screws holding the table top. There are two at the left corners
and one at the right back corner, looking down from the top.
3. Slide the table top to the left until it clears the control panel.
4. Referring to Figure 3-12, adjust the Table End Stop as pictured.

MOVE UNIT TO DESTINATION (VERTICAL POSITION)

Follow the procedure below to move the unit:
1. Remove the small end pallet.
2. Loosen the end brackets (this is necessary in order to mount the tilt arms).
3. Locate the tilt arms packed with the unit (see Figure 3-6), and mount the arms on the end
of the unit using the jam nuts on the leveling feet and end bolts. Tighten the end
brackets.
4. Install the cross brace (shipped screwed to the wooden table shelf) being careful not to
scratch the paint.
5. Remove the four hold-down brackets (see Figure 3-12).
6. Remove the remaining corner brace.
7. Lock the casters.
8. Tip the unit on end as shown in Figure 3-9 (a 1 x 6 board, or equivalent, can be used to
protect the floor).
9. Move the unit, and everything that shipped with it, to the destination room.
