Hologic QDR 4500 Technical Manual page 36

Table 2-9. Control Panel Controller/Control Panel Interconnection
Descriptions
Signal
L0_PWR*
L1_PWR*
L2_PWR*
L3_PWR*
L4_PWR*
L5_PWR*
L6_PWR*
L7_PWR*
TZ_PWR*
XRAY_LIGHT_PWR*
SW0
SW1
SW2
SR0
SR1
SR2
MAN_TZ_UP
MAN_TZ_UP_RET
MAN_TZ_DOWN
MAN_TZ_DOWN_RET
EMERGENCY_CPANEL
HW_EMERGENCY_RET
+5V
Notes: 1. CPC
2. CP
2-14
®
QDR 4500 Technical Manual
Description
Turns on the ENABLE switch LED.
Turns on the HOME switch LED.
Turns on the LOAD switch LED.
Turns on the TABLE switch IN/OUT LED.
Not used.
Turns on the C-ARM switch RIGHT/LEFT LED.
Not used.
Turns on the Laser LED.
Turns on the TABLE UP LED.
Turns on the X_RAY LED
Control signal to determine the state of the C-ARM and
LASER switches.
Control signal to determine the state of the TABLE
IN/OUT switches.
Control signal to determine the state of the LOAD, HOME
and ENABLE switches.
Returns the state of the C-ARM switch LEFT position
when SW0 is active. Signals the state of the TABLE
switch IN position when SW1 is active. Signals the state
of the LOAD switch when SW2 is active.
Returns the state of the C-ARM switch RIGHT position
when SW0 is active. Signals the state of the TABLE
switch OUT position when SW1 is active. Signals the
state of the HOME switch when SW2 is active.
Returns the state of the LASER and ENABLE switches
when SW2 is active.
Returns the state of the TABLE switch UP position.
Not Used.
Returns the state of the STOP switch. (Part of the safety
daisy chain.)
Provides power for the Control Panel LEDs.
= Control Panel Controller
= Control Panel
1 2
CPC CP
Pin Pin
JP6-11 JP1-11
JP6-12 JP1-12
JP6-13 JP1-13
JP6-14 JP1-14
JP6-15 JP1-15
JP6-16 JP1-16
JP6-17 JP1-17
JP6-18 JP1-18
JP6-20 JP1-20
JP6-19 JP1-19
JP6-4 JP1-4
JP6-5 JP1-5
JP6-6 JP1-6
JP6-1 JP1-1
JP6-2 JP1-2
JP6-3 JP1-3
JP6-7 JP1-7
JP6-8 JP1-8
JP6-9 JP1-9
JP6-10 JP1-10
JP6-23 JP1-23
JP6-24 JP1-24
JP6-21 JP1-21
JP6-22 JP1-22
