Hologic QDR 4500 Technical Manual page 19

SPECIFICATION MODEL DEFINITION
Operating
All
Temperature:
Humidity: All
Footprint:
C-arm not
rotated, table not
extended
C-arm rotated,
table extended
C-arm not rotated
SL
C-arm rotated
SL
table extended
W
table not
W
extended
Average Heat
ALL
Load:
A,SL
Patient Table
Height:
W,C
Positioning Laser: All
A,SL
X-ray Collimation:
W,C
A,SL
Lateral Tracking:
C,W
Leakage Current: All
A/SL
Resolution:
C/W
Section 1 - Introduction
o o o
15 - 32 C (60 - 90
20 - 80% relative Humidity, non-condensing
Length
m inches
A 2.02 79.5
A 3.02 119
2.02 79.5
2.02 79.5
3.02 119
2.02 79.5
C 2.02 79.5
1000w (3400 BTU/hr)
Adjustable, 71cm (28") from floor when scanning in AP mode
71cm (28")
Laser Diode (<1mW) cross hair, with emergency mechanical
shutter
Selectable by scan type
1.0mm slit
Exam table is capable of moving +/-2.54cm (1.0") in the x-axis
from center location with scan arm in lateral position.
N/A
Normal <75µA
1 line pair/mm
0.5 line pair/mm
o
F)
Width
m inches
1.40 55
1.50 59
1.40 55
1.50 59
1.50 59
1.22 48
1.40 55
Single Fault <400µA
(approximately 0.5mm)
(approximately 1.0mm)
Height
m inches
1.42 56
1.42 56
1.42 56
1.42 56
1.42 56
1.42 56
1.42 56
1-9
