Summary of Contents for HUANUO HNQF2
- Page 1 Quad Monitor Desk Mount V1.0 HNQF2 support@huanuoav.com...
- Page 2 UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged. Do not use damaged or defective parts.
- Page 5 Option A: Desk Clamp Assembly 1.Install the C-Clamp Brace(c) to the Pole(a) with 3 pcs of M5x14 Bolts. Tighten the bolts with the provided Allen Key(o). See Figure 1. 2.Install the C-Clamp(b) to the pole assembly according to the thickness of the desktop.
- Page 6 Option B: Grommet Base Assembly 2.Install the Grommet Base Plate(m) to the Pole(a) with 3 pcs of M5x14 Bolts(f). Tighten the bolts with the Allen Key(o). See Figure 5. 3.Position the Pole(a) on the mounting surface. Install the spring washer(l) and M10 washer(k) to M10 Bolt(i).
