- Page 1 INSTRUCTION MANUAL Rev00(A) HNQF2 Desk Monitor Arm (US/CA) 1-800-556-0533 support@huanuoav.com (UK) 44-808-196-3874 www.huanuoav.com WWW.
- Page 2 Before getting started, let's make sure this mount is compatible. Is the VESA pattern Yes - Perfect! of your monitor 75 x 75mm (3" x 3") to 100 No - This mount is NOT x 100mm (3.9" x 3.9")? compatible. Does your monitor Yes - Perfect! (including accessories)
- Page 3 Contents Pole Set C Clamp C Clamp Brace Swivel Arm a x 1 b x 1 c x 1 d x 2 VESA Plate M5 x 14mm Bolt M8 x 10mm Bolt e x 4 f x 3 g x 2 h x 4 M10 Washer Spring Washer...
- Page 4 Pre-Assembly Assemble the pole [a]. Step 1 Install the Pole to the Desktop Option A: Desk Clamp Assembly 1A-1 Secure the C clamp brace [c] to the pole [a] with the bolts [f], and attach the soft pad [w1]. Then select the proper mounting holes according to the desk thickness to attach the C clamp.
- Page 5 Option B: Grommet Base Assembly NOTE: 1. If the existing grommet hole comes with a plastic protector, remove it to ensure a flat surface before Phillips Screwdriver installing the desk mount. (Not lncluded) 2. If your desk does not have an existing grommet hole, make a mark on the desktop, then use a drill to drill a hole through the mounting surface.
- Page 6 Step 3 Attach the VESA Plate to the Monitor Option A: For Flat Back Monitor The hanging tab is directed toward the top of the monitor. Option B: For Curved Back Monitor The hanging tab is directed toward the top of the monitor. Step 4 Attach the Monitors to the Mount Slide the monitors to the heads of the swivel arm, and secure them with the nuts [h].
- Page 7 Step 5 Height Adjustment Turn the bolt with Allen key [o1] to raise or lower the monitor. Individual monitor height adjustment helps to perfectly align the monitors. Note: Remove the nut [h] before adjustment. After adjustment, remember to attach the nut [h].
- Page 8 Step 7 Rotation Restriction WARNING: Be careful not to extend the monitors behind the mount or too forward. Ensure that the arms are balanced to maintain center of gravity of the base. Instability may cause the unit to tip over. Correct orientation Correct orientation Incorrect orientation...
