- Page 1 Genmitsu 1010 XY-Axis Extension kit for PROVerXL 4030 V1.0 Feb.2022...
- Page 2 Thank you for purchasing the Genmitsu 1010 XY-Axis Extension kit for PROVerXL 4030. For technical support, please email us at support@sainsmart.com. Help and support is also available from our Facebook group. (SainSmart Genmitsu CNC Users Group)
-
Page 3: Package List
Package List 2×M5*20 Screws X-axis Aluminum Extrusion 2×M5*14 Screws 2mm Hexagon Wrench 2×Y-axis Aluminum Extrusion 2.5mm Hexagon Wrench 3mm Hexagon Wrench 2×Front/Back Plate 4mm Hexagon Wrench Cable Management Installation Guide (Drag Chain+Wiring) -
Page 4: Before Installation
Before Installation Uninstall the parts that are marked as Yellow. - Page 5 Before Installation Step 1: Unplug all wiring and uninstall both cable chains. Step 2: Uninstall X limit switch assembly. Step 1 Step 2...
- Page 6 Before Installation Step 3: Uninstall X-Axis stepper motor and stepper motor mount, as well as all parts in blue. Step 4: Uninstall red side plate from one side of X -axis and slide the X-Z assembly off of the X axis. Step 3 Step 4...
- Page 7 Before Installation Step 5: Remove the Spoilboard and the Dust Baffle. Step 6: Remove 2 blue corner brackets of the CNC Base Frame. Step 5 Step 6...
- Page 8 Before Installation Step 7: Remove the Y axis Stepper Motor and 2 blue corner brackets of the CNC Base Frame. Step 8: Remove the Y-Axis Limit Switch Assembly and Limit Block. Step 7 Step 8...
- Page 9 Step 1: After disassembling your PROVerXL 4030, start by installing the longer aluminum extrusions into the blue corner brackets using the same screws as before. All extended parts of the 1010 kit will be installed just the same as their shorter 4030 counterpart, using the screws, spring washers and flat washers that you got from disassembly.
- Page 10 Installation Steps Step 2: Install the coupler and motor, tighten the screws of the coupler after the motor is installed. The left and right sides are installed in the same way.
- Page 11 Installation Steps Step 3: Use the removed screws to install the Y-Axis limit blocks and limit switches, then adjust the limit switches distance.
- Page 12 Installation Steps Step 4: Install the mounting block and gantry assembly using the removed screws. The left and right sides are installed in the same way.
- Page 13 Installation Steps Step 5: Firstly, remove the side panel of the X-axis gantry (the side without the shaft), then slide on the X-Z assemble so that the holes on the rear plate are aligned with the holes on the slider. With the X-Z assembly installed, put the side panel back on and re-install all screws.
- Page 14 Installation Steps Step 6: Install the left and right gantry arms with the removed screws.
- Page 15 Installation Steps Step 7: Install the X-axis limit blocks with the removed screws and adjust the limit switches distance.
- Page 16 Installation Steps Step 8: Install the X-axis drag chain fastener using the removed screws.
- Page 17 Installation Steps Step 9: Install the X-axis drag chain using the removed screws.
- Page 18 Installation Steps Step 10: Install the Drag Chain Mount and Drag Chain with the removed screws.
- Page 19 Installation Steps Installation Completed...
-
Page 20: Parameter Setting
Parameter Setting 1. Enter $$ in Candle or other software control 2. Check the original parameters and modify them port (console) following: $21=1 $22=1 $27=3 $30=10000 $100=200 $101=200 $102=160 $110=2000 $111=2000 $112=2000 $120=300 $121=300 $122=300 $130=1000 $131=1000 $132=55... - Page 21 Genmitsu Desktop CNC & Laser www.sainsmart.com support@sainsmart.com Vastmind LLC, 5892 Losee Rd Ste. 132, N. Las Vegas, NV 89081...
