Parts List; Assembly Steps - HOMCOM A91-082 Owner's Manual

PART No. DESCRIPTION
1 Fount leg
2 Upper Support Frame
3 Cushion Holder
4 Main Frame
5 Back Cushion
6 Hexagonal Bolt(M8-60mm)
7 Washer(M8)
8 Nut(M8)
9 Safety-Hook
10 Washer(M6)
11 Screw(M6*50MM)
12 Knob nut
13 Circular Foam Grip( Φ73* Φ23* Φ40mm)
14 End plug( Φ25.4)
15 Square cap(38*38mm)
16 Round End cap( Φ38)
PART

ASSEMBLY STEPS

3
QTY
1
1
2
1
1
1
2
1
1
4
4
2
6
6
2
1
