Mechanical Clamp VCMC-R QUICK
Operating instructions
Note
The Operating instructions were originally written in German. Store in a safe place for future reference. Subject
to technical changes without notice. No responsibility is taken for printing or other types of errors.
Published by
© J. Schmalz GmbH, 10/21
This document is protected by copyright. J. Schmalz GmbH retains the rights established thereby. Reproduction of
the contents, in full or in part, is only permitted within the limits of the legal provisions of copyright law. Any mod-
ifications to or abridgments of the document are prohibited without explicit written agreement from
J. Schmalz GmbH.
J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: +49 7443 2403-0
schmalz@schmalz.de
EN-US · 30.30.01.03049 · 00 · 10/21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schmalz VCMC-R QUICK
Summary of Contents for Schmalz VCMC-R QUICK
- Page 1 Any mod- ifications to or abridgments of the document are prohibited without explicit written agreement from J. Schmalz GmbH. J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: +49 7443 2403-0 schmalz@schmalz.de EN-US · 30.30.01.03049 · 00 · 10/21...
-
Page 2: Table Of Contents
Contents Contents 1 Important Information ........................... 3 Note on Using this Document ...................... 3 The technical documentation is part of the product ................ 3 Type Plate ............................ 3 Warnings in This Document........................ 3 Symbol.............................. 3 2 Fundamental Safety Instructions........................ 4 Safety .............................. 4 Intended Use............................ -
Page 3: Important Information
ð Failure to follow the instructions in these Operating instructions may result in injuries! ð Schmalz is not liable for damage or malfunctions that result from failure to heed these instructions. If you still have questions after reading the technical documentation, contact Schmalz Service at: www.schmalz.com/services... -
Page 4: Fundamental Safety Instructions
Intended use includes observing the technical data and the installation and operating instructions in this manual. 2.3 Non-Intended Use Schmalz accepts no liability for damages resulting from use other than as intended. In particular, the following are considered non-intended use: •... -
Page 5: Workplace Requirements
2.6 Modifications to the Product Schmalz assumes no liability for consequences of modifications over which it has no control: 1. The product must be operated only in its original condition as delivered. -
Page 6: Design Of Mechanical Clamp (Vcmc)
3.2 Design of Mechanical Clamp (VCMC) Base plate Main body Clamping range Clamping disc Locking disk NFC interface Extension Clamping surface Sealing frame, 2 sizes Positioning insert, 3 pairs (5, 6 and 6.5 mm) Mounting positions for enclosed positioning Vacuum feedthrough brackets (30, 40 and 50 mm grid) 3.3 ... -
Page 7: Technical Data
For the best data connection, center the reading de- vice on the NFC symbol. The reading distance is very short for NFC applications. If necessary, find the position of the NFC an- tenna in the reading device used. The following parameters can be queried via NFC: •... -
Page 8: Dimensions
1. Compare the entire delivery with the supplied delivery notes to make sure nothing is missing. 2. Damage caused by defective packaging or occurring in transit must be reported immediately to the carrier and J. Schmalz GmbH. 6 Installation 6.1 Installation Instructions The VCMC-R is designed for grid tables with grids measuring 30x30, 40x40 and 50x50 and slot widths between 5 and 7 mm. - Page 9 The VCMC-R can be used for a variety of grid ta- Grid-dependent positions for positioning inserts and sealing bles by selecting and positioning the appropriate frame sealing frame and positioning inserts: Sealing frame • Position A, size 150x150 mm for 50 mm grid •...
- Page 10 3. Mount the appropriate positioning inserts in the corresponding mounting positions. 4. Place the mechanical clamp on the grid table. Make sure that there is an open vacuum feedthrough in the grid table within the sealing frame. 5. Check the position. ð...
-
Page 11: Setting The Clamping Height
6.3 Setting the Clamping Height CAUTION When the clamping disc is lowered, body parts may be present in the clamping range Crushing of body parts 4 Ensure that the clamping height is set so that the distance between the clamping disc and the workpiece is less than or equal to 6 mm. -
Page 12: Changing The Clamping Range
ð The clamping disc is adjusted to the necessary clamping height. ð The quick adjustment mechanism is locked. 4. Closing the quick adjustment mechanism: Turn the locking disc clockwise as far as possible and tighten (hand-tight) to close the quick adjustment mecha- nism. -
Page 13: Start Of Operations
The following steps are required to remove the extension (1): 1. Important: Close the quick adjustment mechanism up to the stop (see section “Setting the Clamping Height, step 4”). 2. Turn the complete clamping disc counterclockwise. While doing so, fix the piston rod (2) to the hexag- onal mid section using a size 24 open-ended wrench (SW24). -
Page 14: Machining Limitations
Schmalz assumes no liability for damages resulting from slippage or release of workpieces due to faulty adjustment of machining parameters. -
Page 15: Releasing The Workpiece
8 Warranty Schmalz guarantees this system pursuant to our General Terms and Conditions of Sale and Delivery. The same ap- plies to spare parts, provided that these are original parts supplied by us.
