Mechanical Clamp VCMC-S4 QUICK
Operating instructions
Note
The Operating instructions were originally written in German. Store in a safe place for future reference. Subject
to technical changes without notice. No responsibility is taken for printing or other types of errors.
Published by
© J. Schmalz GmbH, 10/21
This document is protected by copyright. J. Schmalz GmbH retains the rights established thereby. Reproduction of
the contents, in full or in part, is only permitted within the limits of the legal provisions of copyright law. Any mod-
ifications to or abridgments of the document are prohibited without explicit written agreement from
J. Schmalz GmbH.
J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: +49 7443 2403-0
schmalz@schmalz.de
EN-US · 30.30.01.03007 · 00 · 10/21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schmalz VCMC-S4 QUICK
Summary of Contents for Schmalz VCMC-S4 QUICK
- Page 1 Any mod- ifications to or abridgments of the document are prohibited without explicit written agreement from J. Schmalz GmbH. J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: +49 7443 2403-0 schmalz@schmalz.de EN-US · 30.30.01.03007 · 00 · 10/21...
-
Page 2: Table Of Contents
Contents Contents 1 Important Information ........................... 3 Note on Using this Document ...................... 3 The technical documentation is part of the product ................ 3 Type Plate ............................ 3 Warnings in This Document........................ 3 Symbol.............................. 3 2 Fundamental Safety Instructions........................ 4 Safety .............................. 4 Intended Use............................ -
Page 3: Important Information
ð Failure to follow the instructions in these Operating instructions may result in injuries! ð Schmalz is not liable for damage or malfunctions that result from failure to heed these instructions. If you still have questions after reading the technical documentation, contact Schmalz Service at: www.schmalz.com/services... -
Page 4: Fundamental Safety Instructions
Intended use includes observing the technical data and the installation and operating instructions in this manual. 2.3 Non-Intended Use Schmalz accepts no liability for damages resulting from use other than as intended. In particular, the following are considered non-intended use: •... -
Page 5: Workplace Requirements
2.6 Modifications to the Product Schmalz assumes no liability for consequences of modifications over which it has no control: 1. The product must be operated only in its original condition as delivered. -
Page 6: Design Of Mechanical Clamp (Vcmc)
3.2 Design of Mechanical Clamp (VCMC) Base plate with clamping section Main body Clamping range Clamping disc Locking disk NFC interface Extension Clamping surface Sealing Vacuum feedthrough 3.3 Near Field Communication (NFC) NFC (Near Field Communication) refers to a standard for wireless data transfer between different devices over short distances. -
Page 7: Technical Data
The following parameters can be queried via NFC: • Product group • Type • Part number • Index • Serial number • Year of manufacture (encoded) 4 Technical Data 4.1 General parameters Stroke length Z (all) 9 mm Detent spacing 5 mm Clamping range Z 15 to 50 mm &... -
Page 8: Installation
2. Damage caused by defective packaging or occurring in transit must be reported immediately to the carrier and J. Schmalz GmbH. 6 Installation 6.1 Installation Instructions The VCMC is designed for use on suitable console tables. Mounting and removal must be performed only when the device is not pressurized or fixed. -
Page 9: Setting The Clamping Height
ð The VCMC is secured to the vacuum clamping console. 6.3 Setting the Clamping Height CAUTION When the clamping disc is lowered, body parts may be present in the clamping range Crushing of body parts 4 Ensure that the clamping height is set so that the distance between the clamping disc and the workpiece is less than or equal to 6 mm. - Page 10 2. Releasing the catch of the quick adjustment mech- anism: Clasp the clamping disc with both hands and press and hold the locking disc down by about 4 mm. ð This releases the quick-locking mechanism. 3. CAUTION! When the clamping disc is adjusted downward, there is the risk of crushing fingertips in the area shown.
-
Page 11: Changing The Clamping Range
6.4 Changing the Clamping Range CAUTION When the clamping disc is lowered, body parts may be present in the clamping range Crushing of body parts 4 Ensure that the clamping height is set so that the distance between the clamping disc and the workpiece is less than or equal to 6 mm. -
Page 12: Start Of Operations
3. Use a size 24 open-ended wrench to turn the ex- tension (1) counterclockwise and remove it from the clamping disc. 4. Screw the clamping disc clockwise onto the clamp. 5. Open the quick adjustment mechanism (see step 1 above). 6. -
Page 13: Machining Limitations
Schmalz assumes no liability for damages resulting from slippage or release of workpieces due to faulty adjustment of machining parameters. -
Page 14: Warranty
8 Warranty Schmalz guarantees this system pursuant to our General Terms and Conditions of Sale and Delivery. The same ap- plies to spare parts, provided that these are original parts supplied by us. Wearing parts are not covered by the warranty.
