OPERATING MANUAL
LASERMARKER 70
6
5
4
3
2
1
16
Laser receiver
7
8
9
10
11
21
20
19
18
17
13
12
22
FEATURES:
1. Screw of the battery compartment cover
2. Battery compartment cover
3. On/Off button
4. Loud speaker
5. Display
6. LED indicator for the direction «down»
7. LED center indicator
8. Detection sensor
9. LED indicator for the dirqction «up»
10. Frequency adjustment button
11. Sound button
12. Place for mount installation
13. LED indicators of detection
14. Magnets
15. Laser target
16. Mount
DISPLAY:
17. Power indicator
18. Indicator for the direction «up»
19. Middle mark
20. Indicator for the direction «down»
21. Measurement accuracy indicator
22. Sound alarm indicator
