- Page 1 CENTRIFUGAL FAN IN SOUND INSULATED CASING USER’S MANUAL...
-
Page 2: Table Of Contents
Warranty card ....................................13 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the Iso unit and all its modifications. -
Page 3: Safety Requirements
www.blaubergventilatoren.de Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the intake or extract vents in order to ensure the efficient air flow. Do not sit on the unit and do not put objects on it. The information in this user’s manual was correct at the time of the document’s preparation. - Page 4 www.blaubergventilatoren.de Ensure that the unit is switched off from the supply mains before removing the guard. WARNING: If there are any unusual oscillating movements, immediately stop using the unit and contact the manufacturer, its service agent or suitably qualified persons. The replacement of parts of the safety suspension system device shall be performed by the manufacturer, its service agent or suitably qualified persons.
-
Page 5: Purpose
Packing box 1 pc. DESIGNATION KEY 160- 2 E G1 __ Designation example: Fan name Iso – centrifugal fan in sound insulated casing Outlet spigot diameter [mm] Number of poles Power mains specifications E – single phase Options FR1 – integrated speed controller GI1 –... -
Page 6: Technical Data
OVERALL AND CONNECTING DIMENSIONS OF THE FANS Dimensions [mm] Weight Model [kg] Ø D В Н Н1 Iso 100-2E Iso 125-2E Iso 150-2E Iso 160-2E Iso 200-4E MAIN TECHNICAL PARAMETERS OF THE FANS Iso 100-2E Iso 125-2E Iso 150-2E Iso 160-2E... -
Page 7: Design And Functioning
(air flow) in the range from minimum to maximum speed. Iso ... GI1, GTI1, GSI1, G1, GT1, GS1 Iso ... FR1... -
Page 8: Mounting And Set-Up
www.blaubergventilatoren.de MOUNTING AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT. WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT MAINTENANCE AND REPAIR. THE UNIT MUST BE MOUNTED ON A PLANE SURFACE. MOUNTING OF THE UNIT TO AN UNEVEN SURFACE CAN LEAD TO THE UNIT CASING DISTORTION AND OPERATION DISTURBANCE. -
Page 9: Connection To Power Mains
www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. -
Page 10: Technical Maintenance
www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION The technical maintenance includes periodic (once in 6 months ) cleaning of the surfaces from accumulated dust and dirt. •... -
Page 11: Troubleshooting
www.blaubergventilatoren.de TROUBLESHOOTING PROBLEM POSSIBLE REASONS TROUBLESHOOTING Make sure that the unit is properly connected to the power The fan does not start. No power supply. mains and make any corrections, if necessary. The ventilation system is soiled Make sure the air ducts are clean and intact. Clean them if Low air flow. -
Page 12: Manufacturer's Warranty
www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. -
Page 13: Certificate Of Acceptance
www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Centrifugal fan in sound insulated casing Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 14 www.blaubergventilatoren.de...
