Summary of Contents for RAIS attika Q-Tee II
- Page 1 Q-Tee II Q-Tee II C BRUGERVEJLEDNING BEDIENUNGSANLEITUNG USER MANUAL MANUEL D’UTILISATEUR BRUKERVEILEDNING BRUKSANVISNING KÄYTTÖOHJE GEBRUIKERHANDLEIDING...
- Page 2 The production number can be found on the back of the stove.
-
Page 3: Table Of Contents
INSTALLATION MANUAL CONTENTS Installation manual In general Chimney Technical data Specifications Dimensional sketches Information plate Installation Delivery packaging Disposal of packaging Installation instructions Chimney Installation Installation distances Height adjustment Fitting/changing the handle Removing the combustion chamber lining Lubricating hinges installation of smoke outlet for rear outlet Test certificate This manual applies to the following models: Q-Tee II Glass... -
Page 4: Installation Manual
INSTALLATION MANUAL local regulations must be complied with, including for the size of the non-flamma- Thank you for choosing your new RAIS or ble plate, which must cover the floor in ATTIKA product! This installation manual front of the wood-burning stove to pro-... -
Page 5: Technical Data
TECHNICAL DATA The technical data given below includes specifications, dimensional drawings and the information plate. SPECIFICATIONS Danish Technological Institute ref.: 300-ELAB-1882-EN / 300-ELAB-1882-NS Q-Tee II Q-Tee II C Nominal output (kW) Min./Max. Output (kW): 3-8 * 3-8 * Heating area (m 45 - 120 45 - 120 Fireplace insert width/depth/height... -
Page 6: Dimensional Sketches
DIMENSIONAL SKETCHES... - Page 7 DIMENSIONAL SKETCHES...
- Page 8 DIMENSIONAL SKETCHES...
- Page 9 DIMENSIONAL SKETCHES...
-
Page 10: Information Plate
F: Veuillez lire et observer les instructions du mode d'emploi. FR: BOIS Foyer à durèe de combustion limitèe, homologué pour cheminée à connexions multiples. Utiliser seulement les combustibles recommandés. Hergestellt für /Produced for: ATTIKA FEUER AG, Brunnmatt 16, CH-6330 Cham / RAIS A/S, Industrivej 20, DK-9900 Frederikshavn 15a B-VG... - Page 11 FR: BOIS Foyer à durèe de combustion limitèe, homologué pour cheminée à connexions multiples. Utiliser seulement les combustibles recommandés. Hergestellt für /Produced for: ATTIKA FEUER AG, Brunnmatt 16, CH-6330 Cham / RAIS A/S, Industrivej 20, DK-9900 Frederikshavn 15a B-VG VKF-NR: XXXXX...
-
Page 12: Installation
INSTALLATION INSTALLATION The following section explains how to install the wood stove and includes information about the packaging, installation distances etc. DELIVERY PACKAGING Upon delivery, the stove is secured to a transport pallet using four transport safety fit- tings, one in each corner (A). The safety fittings are secured with screws, which must be unscrewed. -
Page 13: Installation Instructions
INSTALLATION Installation instructions The following pages give instructions for the safe and proper installation of this heat- ing appliance in the UK. These instructions cover the basic principles of installation, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with current UK Building Regulations, Local Authority Byelaws and other specifications or regulations as they affect the installation of the stove. -
Page 14: Chimney
Chimney The chimney is the driving force which makes the stove function. In order for the stove to perform satisfactorily the chimney height must be sufficient to ensure the correct draught of 12 to 18 Pa so as to clear the products of combustion and prevent problems of smoke emanating into the room when firing. -
Page 15: Installation
RAIS recommends to consult a building expert. When you choose where to set up your RAIS wood burning stove, you should consider the heat distribution to the other rooms. This will enable you to get the best use out of your stove. - Page 16 The weight of the stove is indicated in the brochure. If the Q-Tee 2 is installed with the RAIS/attika log store, the distance in front of the stove must meet the UK Building Regulations of 300mm.
- Page 17 INSTALLATION DISTANCES IMPORTANT: Please bear in mind that the installation distances on the following pages only apply to the wood-burning stove. The final choice of Chimney solution may have a larger safety distance to the flammable material. The Chimney solution must always be installed in accordance with current building regulations and in a manner that ensures CE-marking compliance.
-
Page 18: Installation Distances
The installation distances applicable to the wood-burning stove are shown below. Bear in mind that the final choice of chimney may have a different safety distance. All dimensions are in mm. Uninsulated flue EE II Rais Q-TEE II Right-angle installation Flammable ceiling brændbart 8426401 EE II grør... - Page 19 All dimensions are in mm. Insulated flue EE II Right-angle installation brændbart Flammable ceiling Rais Q-TEE II EE II rør 8426406 Afstand til brændbart ændbart Isoleret røgrør ør...
- Page 20 The installation distances applicable to the wood-burning stove are shown below. Bear in mind that the final choice of chimney may have a different safety distance. All dimensions are in mm. Uninsulated flue EE II C Rais Q-TEE II C Right-angle installation Flammable ceiling brændbart 8346401 EE II C grør...
- Page 21 All dimensions are in mm. Insulated flue EE II C Right-angle installation brændbart Flammable ceiling Rais Q-TEE II C EE II C rør 8346406 Afstand til brændbart ændbart Isoleret røgrør ør...
-
Page 22: Height Adjustment
Q-Tee II Adjustable feet HEIGHT ADJUSTMENT 8426504 HEIGHT ADJUSTMENT The stove is equipped with four adjustment screws (1) under the stove. Use the adjustment screws to ensure the wood-burning stove stands level. -
Page 23: Fitting/Changing The Handle
Q-Tee II Mounting of the door handle FITTING THE HANDLE 8426505 FITTING/CHANGING THE HANDLE The wood-burning stove comes with a tem- porary handle (1). To remove it, undo the nuts (2). The new handle (3) can now be fit- ted to the stove using the nuts (2). -
Page 24: Removing The Combustion Chamber Lining
REMOVING THE COMBUSTION CHAMBER LINING Q-Tee II Demounting the vermiculite 8426506 REMOVING THE COMBUSTION CHAMBER LINING The combustion chamber lining protects the body of the fireplace insert from the heat of the fire. The large differences in temperature can lead to cracks in the combustion chamber lining. -
Page 25: Lubricating Hinges
LUBRICATING THE HINGES Q-Tee II Lubricating the moving parts. LUBRICATING THE HINGES & LOCK 8426507 The fireplace must be lubricated regularly using the three moving parts on the lock and hinges (see image). Use heat-resistant oil. -
Page 26: Installation Of Smoke Outlet For Rear Outlet
Smoke outlet to rear outlet INSTALLATION OF SMOKE OUTLET FOR REAR OUTLET. The stove is ready for top exit on delivery, but can be changed to rear exit in the fol- lowing way. 1. On the back of the stove there is a knock-out form Q-Tee II that must be knocked free of the back. -
Page 27: Test Certificate
TEST Reg.nr. 300... - Page 28 POSITIV OUTLINE NEGATIV RAIS A/S ATTIKA FEUER AG Industrivej 20 Brunnmatt 16 DK-9900 Frederikshavn CH-6330 Cham Denmark Switzerland www.rais.dk www.attika.ch...
