ENGLISH
RAIS - manual for Rais Q-Tee 2
INSTRUCTIONS FOR INSTALLATION,
USE AND MAINTENANCE
RAIS Q-Tee 2
IMPORTANT INFORMATION
On first lighting the stove you must be careful not to touch the painted
surfaces and it is MOST IMPORTANT that the door is kept slightly 'ajar' in
order for the door seal and sealant to cure.
This will prevent the door seal sticking to the painted body and becoming
damaged.
1
Q-Tee 2 Manual
January 2014

Advertisement

loading
Need help?

Need help?

Do you have a question about the Q-Tee 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RAIS Q-Tee 2

Summary of Contents for RAIS Q-Tee 2

  • Page 1 ENGLISH RAIS - manual for Rais Q-Tee 2 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE RAIS Q-Tee 2 IMPORTANT INFORMATION On first lighting the stove you must be careful not to touch the painted surfaces and it is MOST IMPORTANT that the door is kept slightly ‘ajar’ in order for the door seal and sealant to cure.
  • Page 2 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 3 ENGLISH RAIS - manual for Rais Q-Tee 2 Revision : 1 Date : January 2014 HETAS SUPPLEMENT …………………………………………………….. MANUFACTURERS PLATE ………………………………………………. INTRODUCTION ………………………………………………………….. WARRANTY …………………………………………………….………….. SPECIFICATIONS ………………………………………………………….. INSTALLATION INSTRUCTIONS ………………………………….……… CONVECTION ………………………………………………………….. 14 CHIMNEY …………………………………………………….…………. 14 INSTALLATION ………………………………………………..……... CHANGING THE CHIMNEY CONNECTION ……………………………..
  • Page 4 ENGLISH RAIS - manual for Rais Q-Tee 2 SUPPLEMENTARY INSTALLATION INSTRUCTIONS FOR THE UK MARKET TO BE READ IN CONJUNCTION WITH THOSE IN THE INSTRUCTION BOOKLET READ THE INSTRUCTION BOOKLET AND THESE SUPPLEMENTARY READ THE INSTRUCTION BOOKLET AND THESE SUPPLEMENTARY...
  • Page 5 ENGLISH RAIS - manual for Rais Q-Tee 2 Chimney For the stove to perform satisfactorily the chimney height must be sufficient to ensure an adequate draught of approximately 15 Pa so as to clear the products of combustion and prevent smoke problems into the room.
  • Page 6 ENGLISH RAIS - manual for Rais Q-Tee 2 Approved Document J, to a distance of 30 cm in front of the stove and 15 cm to each side measuring from the door of the combustion chamber Combustion air supply In order for the stove to perform efficiently and safely there should be an adequate air supply into the room in which the stove is installed to provide combustion air.
  • Page 7 ENGLISH RAIS - manual for Rais Q-Tee 2 SUPPLEMENTARY OPERATING INSTRUCTIONS FOR THE UK MARKET TO BE READ IN CONJUNCTION WITH THOSE IN THE INSTRUCTION BOOKLET READ THE INSTRUCTION BOOKLET AND THESE INSTRUCTIONS READ THE INSTRUCTION BOOKLET AND THESE INSTRUCTIONS...
  • Page 8 Approved Smokeless Fuel It is permitted to burn an Approved Smokeless Fuel in the Q-Tee 2. Petroleum coke is not suitable for burning on this stove and will invalidate the guarantee. Your local approved coal merchant will be able to advise you on a suitable approved fuel.
  • Page 9 ENGLISH RAIS - manual for Rais Q-Tee 2 out when the above action is taken then the fire brigade should be called immediately. Do not relight the stove until the chimney and flueways have been cleaned and examined by a professional.
  • Page 10 ENGLISH RAIS - manual for Rais Q-Tee 2 d) that there is an adequate air supply into the room, e) that an extractor fan is not fitted in the same room as the fire. 2. Fire Blazing Out Of Control...
  • Page 11 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 12 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 13 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 14 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 15 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 16 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 17 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 18 12 mm thick and for free standing installations we recommend 575mm in front and 150mm to each side of the stove. If the Q-Tee 2 is installed with the Rais log store, the distance in front of the stove must meet the UK Building Regulations of 300mm.
  • Page 19 ENGLISH RAIS - manual for Rais Q-Tee 2 Placement of Q-Tee II Installation distance from a combustible wall The stove is placed on a non-combustible floor. Using non insulated 150mm I.D. flue pipe, the minimum distance to combustible wall must be 450 mm from the flue.
  • Page 20 ENGLISH RAIS - manual for Rais Q-Tee 2 Placement of Q-Tee II Corner setting 45° The stove is placed on a non-combustible floor. Uninsulated flue Insulated flue Distance to furniture (min.) 1200 mm 1200 mm Distance to flammable materials (min.) B.
  • Page 21 ENGLISH RAIS - manual for Rais Q-Tee 2 Placement of Q-Tee II Installation distance from combustible ceiling, floor and side wall Normal corner setting Uninsulated flue Insulated flue Distance to flammable materials (min.) E. to the side of the wall...
  • Page 22 ENGLISH RAIS - manual for Rais Q-Tee 2 Installation distance from non-combustible wall We recommend a minimum distance to non-combustible material of 50mm ( F ) for clean- ing considerations. It should always be possible to access the flue access door.
  • Page 23 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 24 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 25 ENGLISH RAIS - manual for Rais Q-Tee 2 By setting the interval between position 1 and 2 (firewood) and between position 2 and 3 (approved smokeless fuel) the energy content in the firewood / approved smokeless fuel is used optimally, as there is oxygen as there is oxygen for combustion and for the burning of the pyrolysis gasses.
  • Page 26 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 27 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 28 When fuelling the door should be opened carefully to prevent smoke exiting the burning chamber. Never add wood / approved smokeless fuel before there is a layer of embers, RAIS recommend to add 2-3 kgs of wood / approved smokeless fuel within 3 hours (intermittent operation).
  • Page 29 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 30 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 31 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 32 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 33 ENGLISH RAIS - manual for Rais Q-Tee 2 PROBLEM SOLVING Q-Tee 2 Manual January 2014...
  • Page 34 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 35 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 36 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 37 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 38 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 39 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 40 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 41 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 42 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 43 ENGLISH RAIS - manual for Rais Q-Tee 2 Q-Tee 2 Manual January 2014...
  • Page 44 ENGLISH RAIS - manual for Rais Q-Tee 2 U K Distributor. Robeys Ltd. Riverside, Goods Road, Belper, Derbyshire, England. DE56 1UU Tel: 01773 820940 Fax: 01773 820477 E Mail: info@robeys.co.uk www.robeys.co.uk May 2013 Q-Tee 2 Manual January 2014...
