- Page 1 USER'S MANUAL 4LEDKIT-COB 4×30W RGB 3in1 LED PAR COB KIT Please read this manual carefully and proper take care of this manual.
- Page 3 ENGLISH Dear customer, First of all thanks far purchasing a SOUNDSATION® product. Our mission is to satisfy all possible needs of musical instrument, professional audio and lighting users offering a wide range of products using the latest technologies. We hope you will be satisfied with this item and, if you want to collaborate, we are looking for a feedback from you about the operation of the product and www.
- Page 4 ENGLISH...
-
Page 5: Table Of Contents
ENGLISH TABLE OF CONTENTS 1. GETTING STARTED ....................6 1.1 Important Safety Symbols ..................6 1.2 Important Safety Instructions ................6 1.3 Before You Start ....................8 2. MACHINE CONNECTION ..................9 3. FEATURES ......................10 4. BAR PANEL ......................11 5. DISPLAY .........................11 5.1 LED display Operation ..................12 6. -
Page 6: Getting Started
ENGLISH 4LEDKIT-COB User’s manual 1. GETTING STARTED 1.1 Important Safety Symbols The symbol is used to indicate that some hazardous live termi- nals are involved within this apparatus, even under the normal operating conditions, which may be sufficient to constitute the risk of electric shock or death. - Page 7 ENGLISH 4LEDKIT-COB User’s manual Heat The apparatus should be located away from heat sources such as radiators, stoves or other appliances that produce heat. Fixture may carry high heat, do not aim at objective exceeding 2 minutes. Ventilation The unit must be installed in a location with adequate ventilation, at least 5m away from adjacent surfaces.
-
Page 8: Before You Start
ENGLISH 4LEDKIT-COB User’s manual Cleaning Clean only with a dry cloth. Do not use any solvents such as benzene or alco- hol. Servicing In case of failure or malfunction occurred, stop using the unit immediately. Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. -
Page 9: Machine Connection
ENGLISH 4LEDKIT-COB User’s manual must be replaced with fuses of the same type and specification. Make sure that all units must be properly grounded. For your safe- ty, you should never remove any ground connector from electrical devices or power cables, or make them inoperative. -
Page 10: Features
Foot controller by manual. f Voltage: AC100-240V, 50-60Hz. f Power consumption: 100W f LED source: 4pcs RGB 3in1 COB 30W led. 4LEDKIT-COB 4 par lux data of 30 degree beam angle: 931 lux@1m 250 lux@2m 45 lux@5m 1299 lux@1m... -
Page 11: Bar Panel
ENGLISH 4LEDKIT-COB User’s manual 4. BAR PANEL DISPLAY SLAVE MASTER SOUND MENU DOWN UP ENTER FOOT AC OUT AC OUT DMX OUT DMX IN CONTROLLER AC IN 100-240V/50-60Hz 100-240V/50-60Hz 100-240V/50-60Hz 1. DMX IN & OUT: 3-poles XLR Male/Female connectors for DMX512 protocol communication 2. -
Page 12: Led Display Operation
ENGLISH 4LEDKIT-COB User’s manual MASTER strobe Master mode SOUND strobe Sound active 5.1 LED display Operation When choose a function, press MENU button, select menu options you want. Press ENTER button to the selected function, the display will be flash, then press UP/DOWN button to select the required function, press ENTER button, or wait for 10 seconds or press MENU button, then enter the menu mode. -
Page 13: Channel Mode Instructions (Choose Default Address Code)
ENGLISH 4LEDKIT-COB User’s manual 6. CHANNEL MODE INSTRUCTIONS (choose A001 fault address code) DMX512 Address Setting Addr Choose press ENTER button to confirm. Press UP/DOWN button to Addr initial address, and press ENTER button to save, After 10 seconds or press MENU long time to return to main menu. -
Page 14: How To Operate
ENGLISH 4LEDKIT-COB User’s manual LED display led_ press ENTER button to confirm. Press UP/DOWN button to Choose led_ (light off) mode. After chosen, press ENTER choose (light up) or _on_ _off button to save. After 10 seconds or press MENU long time to return to main menu. -
Page 15: Channel Mode
ENGLISH 4LEDKIT-COB User’s manual 7.3 Foot controller MENU Strobe Select color Select Show Show Speed Synchronous 1. Red Show 1 Speed 1 strobe in white 2. Green Show 2 Speed 2 3. Blue Show 3 Speed 3 Sound strobe 4. Red+Green... - Page 16 ENGLISH 4LEDKIT-COB User’s manual Channel Number Function 000-255 Red dimmer, 0-100% 000-255 Green dimmer, 0-100% 000-255 Blue dimmer, 0-100% Channel Number Function 000-255 R dimmer, 0-100% 000-255 G dimmer, 0-100% 000-255 B dimmer, 0-100% 000-255 Dimmer 0-100% 000-007 Remain the same...
- Page 17 ENGLISH 4LEDKIT-COB User’s manual 000-255 The forth par, G dimmer, 0-100% 000-255 Dimmer 0-100% 000-007 Remain the same 008-247 Strobe, slow to fast 248-255 Sound active and strobe 000-247 Remain the same 248-255 LED color change 1-16 000-255 Sound control mode, Show 1-16...
-
Page 18: Warranty And Service
Alternatively you can send the product to SOUNDSATION SERVICE CENTER – Via Enzo Ferrari , 10 – 62017 Porto Recanati - Italy . In order to send a product to ser- vice center you need an RMA number. -
Page 19: Warning
