IP2371EN • 2022-03-17
Ditec LCA85
Control panel installation manual for automations with
one 230 V~ motor
(translation of the original instructions)
F1
F5A
LP
L
N
Power supply
Alimentazione
230 V~
230 V~
50/60 Hz
50/60 Hz
respect
polarity L-N
www.ditecautomations.com
24 V~
Push button panel - PT3
~
U W V
1~
AUX1
30
1
AUX2
30
1
SCI
COM
J29
(optional)
ESC
ENTER
DOWN
G3
13
30 2 3 4 9
1 6R 8R
0
11A
12A
30 5 20
AUX2
AUX1
JR1
R
A
UP
D
I
O
R
X
0 1 6 8 41

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCA85 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DITEC LCA85

Summary of Contents for DITEC LCA85

  • Page 1 IP2371EN • 2022-03-17 Ditec LCA85 Control panel installation manual for automations with one 230 V~ motor (translation of the original instructions) AUX1 AUX2 AUX2 AUX1 24 V~ Push button panel - PT3 (optional) ENTER DOWN 30 2 3 4 9...

  • Page 2: Table Of Contents

    Standard installation ................................13 3.2.2 Wiring diagram ..................................14 Standard installation 230 V~ barrier ........................15 3.3.1 Ditec QIK4E standard installation wiring diagram ........................15 Commands and safety devices .........................16 Command inputs ..............................16 Safety inputs ................................16 Limit switch inputs ..............................17 Outputs and accessories ..........................17 Jumper setting ..............................18...

  • Page 3: General Safety Precautions For The User

    General safety precautions for the user ATTENTION! Important safety instructions. Please follow these instructions carefully. Failure to observe the information given in this manual may lead to severe personal injury or damage to the equipment. Keep these instructions for future reference. WARNING! Disconnect power supply before any cleaning or maintenance operation.
  • Page 4 have been instructed in the safe use of the device and the rela- tive hazards • Children must be supervised to make sure they do not play with the device, nor play or remain in the area of action of the motorized door or gate. Keep remote controls and/or any other command devices out of the reach of children, to avoid any accidental activation of the motorized door or gate •...

  • Page 5: General Safety Precautions For Technical Personnel

    General safety precautions for technical personnel ATTENTION! Important safety instructions. Please follow these instructions carefully. Failure to observe the information given in this manual may lead to severe personal injury or damage to the equipment. Keep these instructions for future reference. This manual and those for any accessories can be downloaded from www.ditecautomations.com.
  • Page 6 motorized door or gate • The safety devices must protect against crushing, cutting, trapping and general danger areas of the motor- ized door or gate. Display the signs required by law to identify haz- ardous areas. Each installation must bear a visible indication of the data identifying the motorized door or gate •...

  • Page 7: Ec Declaration Of Conformity

    Lodjursgatan 10 SE-261 44 Landskrona Sweden Declare under our sole responsibility that the types of equipment with names: DItec LCA85 Control unit for 230 V~ sliding gate and barrier operators Ditec LCA85B Control unit for 230 V~ industrial sectional door operators...

  • Page 8: Safety Functions

    1. Safety functions The Ditec LCA85 control panel has the following safety functions: - obstacle recognition with force limiting. The maximum response time of the safety functions is 0.5 s. The reaction time to a faulty safety function is 0.5 s. The safety functions comply with the standards and performance level indicated...

  • Page 9: Installation And Electrical Connections

    3. Installation and electrical connections • For wall-mounted control unit: - Perforate the relevant points in the bottom part of the box (Fig. 3.1 - only for wall installation). - Fix the control panel firmly in place. You are advised to use convex head screws (max head Ø10 mm) with a cross imprint (the centre distance for the holes is shown in Fig.
  • Page 10 Fig. 3.1 Fig. 3.2 Fig. 3.3 Fig. 3.4 Fig. 3.5...

  • Page 11: Cross Installation

    3.1 CROSS installation 3.1.1 Standard installation Ref. Code Description Cable Transmitter Flashing light 230 V 2 x 1 mm² FL24 Flashing light 24 V RG-58 coax Antenna (integrated in the flashing light) cable (50 Ω) AXK5 Key selector switch 4 x 0.5 mm² AXR7 Transponder AXK4...

  • Page 12: Wiring Diagram

    3.1.2 Wiring diagram...

  • Page 13: Dod14 Installation Or Sectional Door Automations 230 V

    Description Cable Actuator (motor) 4 x 1.5 mm² DOD14 Extra low voltage limit switch unit 3 x 0.5 mm² LCA85/LCA85B Control panel 3G x 1.5 mm² Flashing light 230 V 2 x 1mm² FL24 Flashing light 24 V RG-58 coax Antenna (integrated in the flashing light) cable (50 Ω)

  • Page 14: Wiring Diagram

    3.2.2 Wiring diagram...

  • Page 15: Standard Installation 230 V~ Barrier

    3.3 Standard installation 230 V~ barrier 3.3.1 Ditec QIK4E standard installation wiring diagram NOTE: Wiring diagram if purchased as spare part for QIK4E.

  • Page 16: Commands And Safety Devices

    4. Commands and safety devices You are advised to read paragraph 11 for all the details about the possible adjustments. WARNING: terminal 30 (common positive for commands) has the same functions as terminal 1 and for this reason, the commands visible on the display are indicated with 1-5, 1-3, 1-4, etc.

  • Page 17: Limit Switch Inputs

    Command Function Description For safety devices with self-test input: When selecting → CLOSING/OPEN- → , connect the output contact of the safety device ING SAFETY to terminals 1-6-8 on the control panel (in series with the DEVICE photocell output contact, if installed). →...

  • Page 18: Jumper Setting

    NOTE: to activate the closing operation, connect the connector of the push-button panel to J29 (rotated by 180°). (optional Membrane push-button panel (PT3). Causes the blocking of the movement. for LCA85 See parameter → - included Membrane push-button panel (PT3). Starts the closing operation.

  • Page 19: Using Menus

    7. Using menus NOTE: pressure on the keys may be quick (less than 2s) or prolonged (longer than 2s). Unless specified otherwise, quick pressure is intended. To confirm the setting of a parameter, prolonged pressing is necessary. 7.1 Switching the display ON and OFF The procedure to switch on the display is as follows: ENTER •...

  • Page 20: Menu Map

    7.3 Menu map NOTE: depending on the type of automation and operating mode, some menus may not be available. Automatic closure Deceleration distance on Selection of enabling closing automation type Adjustment of thrust on Selection of the Automation status obstacles during opening direction mode at switch-on Adjustment of thrust on...
  • Page 21 Alarm reset Display mode Remote control storage Display of min/max temperatures recorded Courtesy light switch-on Visualisation of number of time remote controls stored Mains power frequency Switch-on time for detected Maximum number of independently commanded remote controls that can courtesy light be stored in the integrated memory Firmware update...

  • Page 22: Setting Up Product For First Use

    8. Setting up product for first use Use the WIZARD (WZ) wizard or the level two AT menu (automatic configuration) to set the product up rapidly with a quick configuration procedure [see parag. 9.2]. For detailed, customised configuration, use the main menus 8.1 Wizard configuration menu (WZ) To access the WZ quick configuration wizard menu: Hold down the ENTER button for 2 seconds.
  • Page 23 D6 - Selection of device connected to terminals 1-6 • NO: none. • SE: safety sensing edge (if contact 1-6 opens, 10 cm disengagement is implemented after stop). • S41: safety edge with safety test (if contact 1-6 opens, after the stop there is a disengagement of a duration depending on the selection →...

  • Page 24: Basic Start-Up Example

    8.2 Basic start-up example 8.2.1 Sliding gate WARNING: the system must have sufficiently robust mechanical end stops WARNING: if the control panel is used to replace an identical control panel which is faulty, the last automation configuration can be recovered by inserting the old control panel storage module into the new control panel and loading the last set configuration using the menu sequence →...

  • Page 25: Sectional Door

    8.2.3 Sectional door WARNING: if the control panel is used to replace an identical control panel which is faulty, the last automation configuration can be recovered by inserting the old control panel storage module into the new control panel and loading the last set configuration using the menu sequence →...

  • Page 26: Frequently Used Menu Sequences

    8.3 Frequently used menu sequences 8.3.1 Enabling the configurations Step-by-step mode without automatic closure (residential use) DOWN ENTER DOWN ENTER → → → → → → Step-by-step mode with automatic closure 1 min (residential use) [standard settings] DOWN ENTER DOWN ENTER →...

  • Page 27: Synthetic Diagram Of Operation

    8.4 Synthetic diagram of operation WARNING: the parameters shown in the figure must be adjusted to comply with exerted forces as outlined in EN 12453. Full PO/PC = OF PO/PC = 01 PO/PC = 02 TIME Command START-UP PHASE Pre-flashing time: parameters WO (opening) and WC (closure) Acceleration time: acceleration time adjustment - TA (opening) and TQ (closure) Start time (without detecting obstacles): start-up at the maximum power MP - ST (opening and closure)

  • Page 28: Configuration And Settings Menu

    9. Configuration and settings menu NOTE: depending on the type of automation and operating mode, some menus may not be available. 9.1 Main menu Display Description WZ - Quick configuration wizard Quick configuration menu AT - Automatic Configuration The menu allows you to manage the automatic configurations of the control panel. BC - Basic Configuration The menu allows you to display and modify the main settings of the control panel.

  • Page 29: Second Level Menu - At (Automatic Configuration)

    9.2 Second level menu - AT (Automatic Configuration) Selections Display Description available AS - Motor operating mode - 01. Generic automation without deceleration (default) - 02. Sliding gate with deceleration - 03. Barrier with deceleration - 04. Sectional door with deceleration Value DM - Selection of the direction mode LF: opening towards left direction (output axis turns clockwise during opening)

  • Page 30: Second Level Menu - Bc (Basic Settings)

    9.3 Second level menu - BC (Basic settings) Display Description Selections available AC - Enabling of automatic closure OF - Disabled ON - Enabled 1-2 - Dependent on input 30-2 hR - Push-to-operate “dead man” closure (independently of setting of parameter R9) hr - Push-to-operate “dead man”...

  • Page 31: Additional Configurable Bc Level Parameters Available With → Enabled

    9.3.1 Additional configurable BC level parameters available with → enabled Display Description Selections available C5 - Operation of command associated with contact 30-5 (wakeup from stand-by) 1-3 - Opening 1-5 - Step-by-step LG - Courtesy light command NO - Input 5 disabled 35 - Operation of command associated with contact 30-3 1-3 - Opening 1-5 - Step-by-step...
  • Page 32 TP - Setting of automatic closing time after partial opening [s] It is set with different intervals of sensitivity. from 0” to 59” with intervals of 1 second; from 1’ to 2’ with intervals of 10 seconds. 30” PO - Deceleration/braking during opening Enables a deceleration phase at the end of the opening stroke OF - Disabled 01 - Speed 50%...
  • Page 33 r2 - Adjustment of thrust on obstacles approaching at constant speed when closing. [%] The control panel is fitted with a safety device which, when it detects an obstacle during the approach phase on closure, determined by parameter → , it reverses the movement. (Default value depends on 00 - Minimum thrust AS setting)

  • Page 34: Additional Ba Level Parameters That Can Be Configured (Available With → Enabled)

    9.4.1 Additional BA level parameters that can be configured (available with → enabled) NOTE: make adjustments gradually and only after performing at least three complete oper- ations to allow the control panel to be set correctly and detect any friction during operations. Display Description Selections available...

  • Page 36: Second Level Menu - Ro (Radio Operations)

    9.5 Second level menu - RO (Radio operations) Display Description SR - Remote control storage You can directly access the Remote control storage menu even with the display turned off, but only with the Display visualisation mode option set to 00 or 03: - for transmitting a remote control not present in the memory;...

  • Page 37: Additional Configurable Bo Level Parameters Available With Enabled

    9.5.1 Additional configurable BO level parameters available with → enabled Selections Display Description available C1, C2, C3, C4 - Selection of CH1, CH2, CH3, CH4 function of stored remote control NO - No setting selected 1-3 - Opening command 1-4 - Closing command 1-5 - Step-by-step command P3 - Partial opening command LG - Command to switch the courtesy light on/off...

  • Page 38: Second Level Menu - Sf (Special Functions)

    9.6 Second level menu - SF (Special Functions) Display Description CU - Displaying the control panel firmware version ENTER Release 1.1 [esempio] Release 1.1 [example] → → → SV - Saving user configuration on control panel storage module Selections available ENTER ENTER DOWN...
  • Page 39 Display Description EU - Deletion of user configurations and last configuration set (can be called up from ENTER ENTER → → → 2” 2” AL - Alarm counter Used to view, in sequence, the counters of alarms that have been triggered at least once (alarm code + number of times triggered).

  • Page 40: Second Level Menu - Cc (Cycles Counter)

    9.7 Second level menu - CC (Cycles Counter) Display Description CV - Display of total operations counter ENTER 182 manovre [esempio] 182 operations [example] → → → → CP - Display of partial operations counter ENTER 716 operations [example] 716 manovre [esempio] →...

  • Page 41: Second Level Menu - Ap (Advanced Parameters)

    9.9 Second level menu - AP (Advanced parameters) Display Description Selections available FA - Opening limit switch mode SX: stop limit switch MT: stop limit switch series connected to the motor phase FC - Closing limit switch mode SX: stop limit switch MT: stop limit switch series connected to the motor phase D6 - Selection of device connected to terminals 1-6 NO - None...

  • Page 42: Additional Configurable Ap Level Parameters Available With → Enabled

    9.9.1 Additional configurable AP level parameters available with → enabled NOTE: make adjustments gradually and only after performing at least three complete oper- ations to allow the control panel to be set correctly and detect any friction during operations. Display Description Selections available LU - Setting switch-on time for courtesy light (s)
  • Page 43 SM - Selection of operating mode of device connected to terminals 1-6 00 - During an opening or closing manouvre, the opening of safety contact stops the movement. When the contact is closed again the interrupted manouvre does not resume, and the operator waits for an external command or performs an automatic closure if enabled.
  • Page 44 TB - Permanent display of the internal control panel temperature [°C] WO - Setting of pre-flashing time on opening [s] Adjustment of the lead time for the switch-on of the flashing light, in relation to the start of the opening operation from a voluntary command. 00 - Minimum 05 - Maximum.

  • Page 45: Diagnostics

    10. Diagnostics 10.1 Data Logging integrated in the board The Ditec LCA85 control panel is equipped with an internal system which allows the installer to check whether any alarms have been triggered, see how many times each alarm has been triggered and view a the log of the last twenty alarms.

  • Page 46: Display Of Safety Devices And Commands

    11.2 Display of safety devices and commands NOTE: the safety device and command display mode is only visible with Display visual- isation mode set at 01 or 03. Display Description Display Description 1-2 - Automatic closure enable command. CX - Command received from AUX1 board 1-3 - Opening command.

  • Page 47: Visualisation Of Alarms And Faults

    11.3 Visualisation of alarms and faults WARNING: the visualisation of alarms and faults is possible with any visualisation se- lection. The signalling of alarm messages takes priority over all other displays. Type of Display Description Operation alarm M3 - Motor blocked or limit switch not re- leased within 3 s M6 - Overrun limit switch opens Check if there are any obstacles and make...
  • Page 48 Type of Display Description Operation alarm Check there is no short circuit in connection I5 - No voltage 0-30 (faulty voltage regula- 0-30. If the problem persists, replace the tor or short-circuit on accessories) control panel. Replace the control panel. I6 - Excessive voltage 0-30 (faulty voltage regulator) Reset.

  • Page 49: Troubleshooting

    Type of Display Description Operation alarm Check the safety device is working properly. A0 - Test of safety sensor on contact 6 failed. If the supplementary safety board is not inserted, check the safety test is disabled. Check the wiring and correct operation of A1 - Test of safety sensor connected si- the safety sensor.

  • Page 50: Maintenance

    Problem Possible cause Alarm signal- Operation ling Incorrect connections between Check that is displayed the photocells and the control Connect NC safety contacts together in panel. External safety series and remove any jumpers on the devices not acti- control panel terminal board. vating Check the →...
