convenience concepts MISSION 09010 Assembly Instructions page 3

STEP 3
Insert Cam Bolts ( b ) into Desk Top ( F ).
STEP 4
Insert Wood Dowels into assembly (a) as shown below.
Place Desk Top ( F ) onto unit assembly and gently tighten cam locks ( c ).
****
Assembling the unit with cam and wood dowels.
A
Gently screw cam
dowel into the
threaded anchor.
B
Lightly glue one end of the
wood dowel and tap halfway
into hole. Add 2nd drop of
glue to top of dowel.
HARDWARE NEEDED
HARDWARE NEEDED
C
Connect to second panel
by inserting dowels into
holes.
b. 4 PCS
a. 4 PCS
c. 4 PCS
g. 1 PC
D
Insert cam lock with
arrow pointing down.
Screw the cam firmly
into locked position.
