Hardware Needed - convenience concepts MISSION 09010 Assembly Instructions

STEP 1
Insert Cam Bolts ( b ) into Side Panels ( A ) & ( B ).
STEP 2
Install Wood Dowels ( a ) as shown below.
Connect Flip Down Front Panel ( H ) to Side Panel ( B ).
Gently tighten cam locks (C).
Repeat process for Top Support Rail ( C ) and Bottom Support Rail ( D ).
Fasten Side Panel ( A ) to unit assembly, gently tighten cam locks .
****
Assembling the unit with cam and wood dowels.
A
Gently screw cam
dowel into the
threaded anchor.
c
a
B
Lightly glue one end of the
wood dowel and tap halfway
into hole. Add 2nd drop of
glue to top of dowel.

HARDWARE NEEDED

HARDWARE NEEDED
C
Connect to second panel
by inserting dowels into
holes.
b. 6 PCS
a.
8 PCS
c. 6 PCS
g. 1 PC
D
Insert cam lock with
arrow pointing down.
Screw the cam firmly
into locked position.
