3.3 Diagnostics Toolbar

The diagnostics toolbar contains a number of buttons that allow you to print the
displayed data or make other controls. It is displayed on the upper right corner of
the screen and goes through the whole diagnostic session. The table below
provides a brief description for the operations of the diagnostics toolbar buttons:
Name
Home
Print
Exit
Button
Returns to Job menu screen.
Tap to print the current screen. Before printing,
you need to configure the wireless printer
following the steps described in Chapter
9.11.3.
Exits the diagnostic application.
X-431 PRO5 User Manual
Description
17
