Gastroback DESIGN MULTI JUICER DIGITAL Operating Instructions Manual page 50

OPTIONAL ACCESSORIES
Problem Reason
The glass jug is lea- The threads of the
king. Water is accu- blade assembly and
mulating under the glass jug have been
blade assembly. tilted.
The sealing ring
is missing or not
inserted correctly.
The junction bet-
ween blade assem-
bly and glass jug is
not screwed on as
tight as necessary.
The sealing surface
of the glass jug is
chipped or broken.
The sealing ring is
damaged.
There are residues
of food sticking to
the sealing surfaces
of the glass jug,
sealing ring, or bla-
de assembly.
You cannot lock the The coupling at
blade assembly on the bottom of the
the motor base. The blade assembly did
glass jug / grinding not slide onto the
cup is wobbling on drive coupling of the
the motor base. motor base.
50
The Solution
Completely unscrew the blade assembly. Then position the
blade assembly newly for screwing it onto the glass container.
Ensure to mount the blade assembly without tilting the thread
to avoid leakage and damage to the thread (See: 'Assembling
the Glass Jugs').
Before turning the blade assembly onto the glass container,
ensure to place a sealing ring in correct orientation into the
groove at the inner rim of the blade assembly. The ridged side
of the sealing ring must face upwards (See: 'Assembling the
Glass Jugs').
Try to turn on the blade assembly a little more tightly. Due to
the sealing ring, there is a firm resistance when screwing on the
blade assembly.
Replace the glass jug. Do not use any chipped or cracked glass
parts for preparing food to avoid injuries due to splinters in your
food!
The sealing ring must be in proper working order. There may
be no tears, cracks, or brittle or worn out parts. Replace the
sealing ring.
Clean all sealing surfaces thoroughly, removing all dried-on
crusts and residues of food (see: 'Cleaning the Optional Acces-
sories').
Without pressure, turn the blade assembly over the drive cou-
pling of the motor base to and fro, until the blade assembly
slides down and comes to a stable stand without any gap. Then
turn the blade assembly clockwise to lock it (see: 'Processing
Your Food').
