ST X-NUCLEO-OUT15A1 Getting Started

Getting started with the X-NUCLEO-OUT15A1 industrial digital output expansion
Introduction
The X-NUCLEO-OUT15A1 is an industrial digital output expansion board for
environment for the evaluation of the driving and diagnostic capabilities of the
solid-state relay in a digital output module connected to 2.5 A industrial loads.
The X-NUCLEO-OUT15A1 interfaces with the microcontroller on the
®
pins and Arduino UNO R3 connectors.
The expansion board can be connected to either a
You can also evaluate a system consisting of an
Supplying the X-NUCLEO-OUT05A1
X-NUCLEO-OUT05A1, you can achieve the typical architecture of a single channel digital output for safety systems. The
process stages of the two expansion boards result cascaded. The load connected to the
supplied only when both cascaded systems are properly working.
UM3036 - Rev 1 - June 2022
For further information contact your local STMicroelectronics sales office.
NUCLEO-F401RE
X-NUCLEO-OUT05A1
through the main supply rail and the
Figure 1. X-NUCLEO-OUT15A1 expansion board
board for STM32 Nucleo
STM32 Nucleo. It provides a powerful and flexible
IPS1025HF single high-side, smart power,
STM32 Nucleo via 5 kV optocouplers driven by the GPIO
or a NUCLEO-G431RB development board.
stacked on an X-NUCLEO-OUT15A1
X-NUCLEO-OUT15A1 through the output of the
X-NUCLEO-OUT15A1
UM3036
User manual
expansion board.
output can be
www.st.com
