Day One+
PTX10004
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 7
Step 3: Keep Going | 11
Step 1: Begin
IN THIS SECTION
Meet the PTX10004 | 1
Install the PTX10004 in a Rack | 2
Power On | 6
In this guide, we provide a simple, three-step path, to quickly get you up and running with your new AC-powered router.
We've simplified and shortened the installation and configuration steps, and included how-to videos. You'll learn how to
install the PTX1004 in a rack, power it up, and configure basic settings.
Meet the PTX10004
®
The Juniper Networks
power-constrained facilities. The PTX10004 supports 400GbE architectures with inline Media Access Control Security
(MACsec) on all ports for uncompromised security. The compact 7-U design and the ability to scale from 19.2 Tbps to
57.6 Tbps makes the PTX10004 perfectly optimized for data center and colocation racks.
PTX10004 modular router is the ultra-compact, ultra-high-density router for today's space-and

Advertisement

loading

Related Manuals for Juniper Day One+

Summary of Contents for Juniper Day One+

  • Page 1 PTX1004 in a rack, power it up, and configure basic settings. Meet the PTX10004 ® The Juniper Networks PTX10004 modular router is the ultra-compact, ultra-high-density router for today’s space-and power-constrained facilities. The PTX10004 supports 400GbE architectures with inline Media Access Control Security (MACsec) on all ports for uncompromised security.
