- Page 1 70L INDUSTRIAL DEHUMIDIFIER MODEL NO: IDH70L PART NO: 6470613 OPERATION & MAINTENANCE INSTRUCTIONS DL0522 Iss 1...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE 70 Litre Industrial Dehumidifier. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 4 OVERVIEW Description Handle Control Panel Air Outlet Lifting Handle 2 x Wheels 2 x Feet 16mm x 90cm Drainage Pipe Air Filter Pull Tab Air Inlet and Filter Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 5: Safety Warnings
3. This appliance is designed to dehumidify industrial environments and MUST NOT be used for other purposes. 4. If the appliance requires repair, ALWAYS contact your CLARKE dealer. ALWAYS insist on original spare parts. Repairs carried out by unauthorized persons may be dangerous and invalidate the guarantee. - Page 6 WARNING: DO NOT USE OR STORE THE DEHUMIDIFIER NEAR A HEAT SOURCE, AS THE UNIT CONTAINS PRESSURISED FLAMMABLE REFRIGERANT GAS (R290-HYDROCARBON PROPANE) R290 REFRIGERANT GAS (HYDROCARBON PROPANE) H220: Extremely Flammable Gas. H280: Contains Gas Under Pressure, May Explode if Heated. R290 refrigerant gas complies with UK &...
- Page 7 ASSEMBLY • Align the fixing holes of the tubular handle with the holes on the rear of the dehumidifier. • Fix the handle to the dehumidifier using the 4 fixing screws supplied, as shown. WHEELS 1. Incline the machine body, as shown, and fix the axle on the bottom of the machine body using the 4 screws.
-
Page 8: Operation
OPERATION CONTROL PANEL 1 = DISPLAY SCREEN 2 = POWER INDICATOR LIGHT 3 = TIMER INDICATOR LIGHT 4 = ON/OFF BUTTON 5 = TIMER SET BUTTON 6 = INCREASE SET TIMER/HUMIDITY BUTTON 7 = DECREASE SET TIMER/HUMIDITY BUTTON Button Operation Instructions On/Off (Button 4) Switches the machine On and Off + (Button 6) - Page 9 PREPARATION FOR CONTINUOUS DRAINING: 1. Locate the prefitted external drainage pipe on the side of the machine. 2. Place the pipe into a suitable receptacle/drain ensuring that the end of the pipe is below the level of the outlet in the unit body. NOTE: If using a receptacle, make sure it is large enough as the machine can produce up to...
-
Page 10: Humidity Control
See Defrosting Mode on Page 11. E2/E3 Fault with humidity and/ Replace temperature and or temperature sensor humidity sensor. Refrigerant leakage Turn off machine and contact CLARKE service department. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 11: Defrosting Mode
DEFROSTING MODE Defrosting Description Mode Automatic Sensor at 1: If the compressor constantly runs for over 20 Defrosting Normal State minutes or if the coil temperature is below 0 constantly for over 30 minutes, it will start the defrosting mode. 2: If the coil temperature is over 5 C for a 90 second period, or the defrosting time is over 8... -
Page 12: Troubleshooting
TROUBLESHOOTING Cause Solution No operation Power outage Check if the power supply is in (Shown as no working order. power) Confirm the plug is correctly inserted in the power socket. Fuse in plug or fuse board Replace the relevant fuse. blown No operation Environmental humidity... -
Page 13: Technical Specification
TECHNICAL SPECIFICATION Power Source AC 220-240V 50Hz Input Current @ Rated Load 4.7A @ 27 C RH 60%, 5.7A @ 30 C RH 80% Power 950W @ 27 C RH 60%, 1300W @ 30 C RH 80% IP Rating IP22 Dehumidifying Extraction Rate 70 litres/day @ 30 C RH 80%... -
Page 14: Maintenance
MAINTENANCE WARNING: ALWAYS UNPLUG THE DEHUMIDIFIER BEFORE PERFORMING ANY CLEANING OR MAINTENANCE OPERATIONS. CLEANING THE CABINET • Use a soft damp cloth to clean the exterior. • Never use harsh chemicals or abrasive cleaning agents as these may damage the casing finish. CLEANING THE AIR FILTER 1. - Page 15 DECLARATION OF CONFORMITY - UKCA & CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
