- Page 1 30 LITRE DEHUMIDIFIER (R290) MODEL NO: DH30L PART NO: 6470685 OPERATION & MAINTENANCE INSTRUCTIONS DL0921 Rev2...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE 30 Litre Dehumidifier. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 4 OVERVIEW Description Control Panel Water Tank Fold Down Carrying Handle Air Outlet 9mm Drainage Pipe Air Inlet and Filter Water Drain Cap and Outlet Power Cable & Plug Holder Power Cable Storage Hooks 4 x Castor Wheel Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 5: Safety Warnings
3. This appliance is designed to dehumidify residential environments and MUST NOT be used for other purposes. 4. If the appliance requires repair, always contact your CLARKE dealer. ALWAYS insist on original spare parts. Repairs carried out by unauthorized persons may be dangerous and invalidate the guarantee. -
Page 6: Safety Symbols
R290 REFRIGERANT GAS (HYDROCARBON PROPANE) H220: Extremely Flammable Gas. H280: Contains Gas Under Pressure, May Explode if Heated. R290 refrigerant gas complies with European environmental directives. R290 has a low GWP (Global Warming Potential) of 3. The dehumidifier contains approximately 52g of R290 refrigerant gas.The refrigerant system MUST NOT be perforated or punctured. - Page 7 SET UP & POSITIONING THE DEHUMIDIFIER WARNING: DO NOT USE OR STORE THE DEHUMIDIFIER NEAR A HEAT SOURCE, AS THE UNIT CONTAINS PRESSURISED FLAMMABLE REFRIGERANT GAS (R290-HYDROCARBON PROPANE) • Empty any water that is in the water tank before every use. •...
-
Page 8: Operation
OPERATION CONTROL PANEL 1 = TIMER (24HR SETUP) Press this button to set the length of time the dehumidifier runs for (1-24 Hours) via the LCD display. To cancel the timer, press the button twice once the timer is set. 2 = DRYING Press this button to start the dehumidifier drying procedure. -
Page 9: Select Mode
SELECT MODE SETTING OF TIMER - OFF • When the dehumidifier is running, press the TIMER button to adjust the time from 1 hour to 24 hours, pressing once for each hour. If the time exceeds 24 hours, the count will reset to 1 hour and will start the cycle again. -
Page 10: Emptying The Water Tank
• The dehumidifier will start at high air speed and release air continuously for 30 minutes. • The dehumidifier will reduce to low air speed and run for 20 minutes. HOW TO STOP • Press the DRYING button again to cancel the drying procedure, which will return the dehumidifier to the running state before the start of the drying procedure. -
Page 11: Continuous Draining
5. Before refitting the water tank, check to confirm the indicator float moves freely. 6. Replace cover and refit the water tank. NOTE: The unit will not operate unless the water tank is fitted correctly. CONTINUOUS DRAINING This function enables continuous dehumidifying without having to empty the water tank. -
Page 12: Maintenance
MAINTENANCE WARNING: ALWAYS UNPLUG THE DEHUMIDIFIER BEFORE PERFORMING ANY CLEANING OR MAINTENANCE OPERATIONS. CLEANING THE CABINET • Use a soft damp cloth to clean the exterior. • Never use harsh chemicals or abrasive cleaning agents as these may damage the casing finish. •... -
Page 13: Troubleshooting
TROUBLESHOOTING Cause Solution No operation Plug fuse failure. Check fuse in plug and replace if necessary. Water tank is full or placed Check water tank and empty if incorrectly. necessary and/or check water tank positioning. The ambient temperature is This machine will not operate outside of these boundaries. -
Page 14: Display Codes
Water Tank is Full. Empty Tank, Empty Tank, See Page 9 See Page 9 Coil Sensor Detects Anomaly, Contact Your CLARKE Contact Your CLARKE Dealer Dealer for Assistance. for Assistance. Room Temperature Sensor Contact Your CLARKE Detects Anomaly, Contact Your Dealer for Assistance. -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
