Section 5 SpO2 Sensors
22
3. For additional support, secure the cable along the limb with tape.
WARNING: Do not wrap the sensor around the limb so tightly that circulation is
restricted. Inspect the site often, at least every four hours, for adequate circulation. When
applying sensors, take note of patients physiological condition. For example, burn patients
may exhibit more sensitivity to heat and pressure and therefore additional consideration
such as more frequent site checks may be appropriate
Single Patient Use SpO
1. With the sensor connected to the monitor but not applied to the patient, position the
sensor heads so that they face each other (the red light shines at the detector). Is
PROBE OFF PATIENT displayed?
2. Apply the sensor to your index finger. Are reasonable SpO
displayed?
3. A YES to BOTH #1 and #2 indicates the sensor is OK. Apply the sensor to the
patient as instructed above.
This quick check also tests the functionality of the DB-9 to OxySnap connector cable.
01-May-96
Sensor Quick Check
2
and pulse rate values
2
Model 511
User's Manual
